High Efficiency CPM Centrifugal Water Pump

1.Product Overview

INTRODUCTION:

The pump is suitable for civil and industrial uses to pump clean water and chemically non-aggressive liquid. They have a compact size and are extremely reliable, very simple to use and almost maintenance-free.

APPLICATION:

Applied to pumping such liquid which is clean, no solid matter or frictional matter, low viscous, noncorrosive, non-crystallizable, chemically neutral and close to water. Such as:

1.  Tank filling

2.  Domestic water supply

3.  Water transfer

4.  Pressure boosting

5.  Irrigation

FEATURES:

1. 100% copper wire, brass impeller and automatic wiring

2. Cold-rolled silicon steel sheet, with high-speed punching, improving the efficiency and precision

3. Demagnetization of stainless steel nuts

4. Anti-rust treatment castings and electrophoresis

5. New testing equipment

6. Certificate: ISO9001, CE, SONCAP, SASO, VOC, EMC,etc

CONSTRUCTION:

Pump body: Cast Iron

Housing: Alloy Aluminum

Impeller: Brass/Plastic/SS

Motor: Electric Motor

Shaft: Stainless Steel/Carbon Steel

Insulation : Class B ( Class F if you required)

Protection : IP44/IP54

Cooling: External Ventilation

Mechanical Seal: Carbon/Ceramic/Stainless Steel

OPERATION CONDITIONS:

Suction head up to 9M
Liquid temperature up to 60C
Ambient temperature up to 40C
Max.Pressure:10Bar

TECHNICAL DATA:
