Specifications
20kva30kva 40kva 50kva 60kva 70kva 80kva 100kva LPG gas generator1)global warranty
2)on site installation
3)low noise
20kva30kva 40kva 50kva 60kva 70kva 80kva 100kva lpg gas generator
Gas generator set feature, specification, price and photos
Gas generator set feature:
1) Our engineer will install the gas generator set on your site.
2) Gas consumption: less than 0.28cbm/kWh
3) We supply you spare parts during the whole service life.
4) Gas generator set powered by famous and good quality engine and alternator, such as Cummins, Deutz.
5) Longer life: gas engine has a life of over several years if it is properly operated and maintained
6) Low operation cost: nature gas has a rich reserve with low cost and a high rate of return
7) High profit: low operation&maintenance cost, supply of electricity and thermal power at the same time.
8) Gas generator set coupled with brushless alternators of Leroy Somer /Stamford/ Marathon, etc.
9) Well performed control system, high quality monitor instrument, with sound and light alarm devices, auto shutdown when main power on, auto start when main power off.
10) Protection function: over-current, under-voltage, auto-regulate voltage, reverse power
11) Monitor function: speed, water temperature, lub-oil temperature, lube-oil pressure, exhaust temperature
12) Supply connection: 3 phase, 4 lines
14) Rated frequency: 50Hz / 60Hz
15) Rated power factor: 0.8
16) Exciting way: brushless
17) Starting mode: 24V DC electric starting system
18) Cooling mode: closed-circuit cooling system
Gas generator set specification:
| Gas generator set | Gas-Engine | Alternator | Overall Size (mm) | Net Weight (kg) | ||
| Model | Rated Power (kW/kVA) | Rated Current (A) | Model | Model | ||
| SPT10GF | 10/12.5 | 18 | SP2100DT | 164C | 1600X650X1250 | 470 |
| SPT20GF | 20/25 | 36 | SP4100DT | PI144E | 2000X730X1320 | 620 |
| SPT30GF | 30/37.5 | 54 | SP4105DT | PI144H | 2100X730X1320 | 760 |
| SPT40GF | 40/50 | 72 | SP6105DT | UCI224D | 2480X800X1320 | 1200 |
| SPT50GF | 50/62.5 | 90 | SP6105DT | UCI224E | 2500X800X1320 | 1250 |
| SPT70GF | 70/87.5 | 126 | SP6135DT | UCI224G | 2550X1010X1430 | 2410 |
| SPT90GF | 90/112.5 | 162 | SP6135ADT | UCI274D | 2550X1010X1470 | 2530 |
| SPT120GF | 120/150 | 216 | SP6140ADT | UCI274E | 2700X1010X1470 | 2600 |
| SPT160GF | 160/200 | 288 | SP12V135DT | UCI274H | 3060X1350X1790 | 3200 |
| SPT200GF | 200/250 | 360 | SP12V138DT | UCI274K | 3060X1350X1790 | 3300 |
| SPT400GF | 400/500 | 720 | SP12V190DT | HCI544D | 4600X2040X2210 | 10700 |
| SPT500GF | 500/625 | 900 | SP12V190ZDT | HCI544FS | 4820X2040X2780 | 12000 |
| SPT700GF | 700/875 | 1260 | SPG12V190ZLDT | HCI634H | 5120X2040X2250 | 11800 |
| SPT800GF | 800/1000 | 1440 | SPA12V190ZLDT | HCI634J | 6190*2110*2800 | 12000 |
| SPT1000GF | 1000/1250 | 1800 | SPAD12V192ZLT2 | PI734A | 6710*2950*3000 | 32000 |
Gas generator set Parameter: |
Voltage: 400/230V, 220/127V,440/254V, 480/277V, etc |
Frequency: 50Hz/ 60Hz Speed: 1500r.p.m / 1800 r.p.m |
Power Factor: 0.8(lagging) |
Protection Standard: IP23 |
Model of Connection: 3 phase 4 lines /1 phase |
Insulation Grade: H |
Frequency Drop(%): ≤ 0.5 |
Transient state frequency deviation(%):(advertised power ) +10~-7 |
Frequency Recovery Time(S): ≤ 3 |
Voltage Recovery Time(S): ≤4 |
Waveform Distortion(%): ≤5 |
After sales promise:
1. Since gas generator set reached the agreed destination, it will be guaranteed within 12 months or 1500 hours.
2. We give technical guide all the service life. In the warranty days, we send spare parts for free. After
warranty, we take the spare parts cost.
3. Daily consumed components, wrong operating, lack of maintenance are not include in the quality guarantee.
Testing Equipment:
Gas generator set on site:
Loading and Shipping
If any problem, welcome contact with me by email or Skype yan8735. thanks.
