On Sale! CE Approved Silent Natural Gas Generator 15kva
Natural gas generator 15kva feature, specification, data and photos.
superiority 1. low running cost, gas consumption: 3.6m³/h @100% load
superiority 2. we install the natural gas generator 15kva on your site after paid charges.
superiority 3. we supply spare parts during the whole service.
superiority 4. one year warranty.
Natural gas generator 15kva specification
| Model of generating sets | SP15GFT |
| Model of engine | SPC4B |
| Rated power KVA | 15 |
| Standby power KVA | 16.5 |
| Rated speed r/min. | 1500 /1800 |
| Rated voltage V | 400/230 |
| Rated frequency Hz | 50 / 60 |
| Rated power factor | 0.8 |
| Gas pressure | 3kpa |
| Gas consumption | 0.32Nm3/kw.h |
| Supply method | 3 phases 4 lines |
| Excitation method | brushless |
| Starting method | 24V DC starter 24V |
| Cooling method | Closed type water cooling(with radiator) |
| Speed modulate method | Electronic control |
| Net weight kg | 1500 |
| Overall dimension L×B×H(mm) | 1800*750*1300 |
Control system of natural gas generator 15kva:
. Key Manual Start Module Engine Control & Monitoring Panel
· Low Oil Pressure , High Water Temp Protection Features
· Tamper-Proof Engine Hour Counter
· Auto/Manual Start
· Simultaneous Multiple Engine Parameters Monitoring
· Remote Start/Stop thru SMS, with GSM SIM Card (on some models)
Controller: Deepsea, Datakom, Smartgen, ComAp, Harsen, etc.
1) Natural gas generator 15kva powered by famous and good quality gas engine and alternator
3) Longer life: natural gas engine has a life of over several years if it is properly operated and maintained
4) Low operation cost: natural gas has a rich reserve with low cost and a high rate of return
5) High profit: low operation cost, supply of electricity and thermal power at the same time, low maintenance cost
6) Natural gas generator 15kva coupled with brushless alternators of Leroy Somer / Engga
7) Well performed control system, high quality monitor instrument, with sound and light alarm devices, auto shutdown
8) Protection function: over-current, under-voltage, auto-regulate voltage, reverse power
9) Monitor function: speed, water temperature, lube-oil temperature, lube-oil pressure, exhaust temperature
Natural gas generator set 15kva photos
Detailed photos of natural gas generator 15kva
Silent type photos of natural gas generator 15kva
Packing and delivery of natural gas generator 15kva
After sales promise
1. Since the gas generator reached the agreed destination, its main parts will be guaranteed within 12 months or 1500 hours.
2. We give technical guide all the service life. In the warranty days, we send spare parts for free. After warranty, we take the spare parts cost.
3. Daily consumed components, wrong operating, lack of maintenance are not include in the quality guarantee.
We are decade years factory with 35000 square meters factory. Welcome to visit us.
If any problem, pls contact with me by email or Skype: elaine19861027.
+Whatapp / viber: +86 15095247272
I will reply asap. thanks.
