Help CenterDual LED Digital DC100V 10A Voltmeter Ammeter Voltage Amps Meter Power DC4.5~30V
Related Products
-
YB27VA DC 4.5-30V/10A Red LED Dual Display Volt Amp Meter 2in1 Three Wires Voltage Current Monitor MeterUS$ 3.50 - 3.50MOQ: 100 Pieces -
YB27VA Dual Display Meter Red Blue LED Car 0-300V/10A Motorcycle DC Amp Meter Volt Gauge Voltmeter Ampere 2-in-1US$ 3.50 - 3.50MOQ: 100 Pieces
-
Digital Ammeter & Voltmeter DC 4.5-30V & 50A With 50A Shunt Red&Blue Led Dual Panel Volt Amp Combo MeterUS$ 5.00 - 5.00MOQ: 100 Pieces
-
Digital Ammeter Voltmeter DC 4.5-30V & 100A With 100A Shunt Red&Blue Led Dual Panel Volt Amp Combo Meter Direct ModeUS$ 6.50 - 6.50MOQ: 100 Pieces
-
DC 4.5-30V 200A Ammeter Voltmeter Red&Blue Led Dual Display Panel Volt Amp Combo Meter With 200A /75mv ShuntUS$ 8.00 - 8.00MOQ: 100 Pieces
-2 in 1 function Voltmeter Ammeter
- Dual color LED Display (Blue andRed)
- Voltages and Amps reading at the same time in display
-This meter test of Voltages and Amps, power supply can taken from the test circle, no additional power supply
- Power supply DC 4.5~30V range (Attention: The maximum of input voltage cannot be exceed of 30V, otherwise would be burnt)
-This meter have three wire for easy to connect a car /battery car/ motorcycle car which can monitor to the battery voltage status. Another products can also use for voltage and current measurement intent.
Features:
-Dual 0.28 " LED, display (Blue and Red) colors
-Power supply DC4.5V~30V
-Measuring range: DC0V~100V (Resolution: 0.1V), DC0~10A (Resolution: 0.01A),50A,100A( Resolution: 0.1A)
-0-10A No need use shunt for measure amps,More than 10A need use shunt
-Measurement rate: ≥ 500mS / times
-Measurement accuracy: 1% ± 1
-Operating Current <60mA
-Operating Temperature: -10°C to +65°C
-Operating Humidity: 10 to 80% (non-condensing)
-Working pressure: 80 ~ 106kPa
-Sun exposure: no direct exposure
-Dimensions: 48 × 29 × 21 mm
-Cutout: 45.5 × 26.5 mm
