Specifications
1,The computer automatic asphalt Cone penetrometer2,automatically control the temperature
3,automatically calculate average
Penetrometer is based on the Ministry of Transportation "JTG E20-2011 highway asphalt and asphalt testing procedures," the latest design and manufacturing requirements. Penetrometer is used to test the needle penetration of petroleum asphalt for road, polymer modified asphalt penetration and liquid petroleum asphalt distillation or the residue after evaporation ofemulsified asphalt recording by 0.1mm.
| Main Technical Indicators | |
| Parameter Names | Details |
| Temperature Range | Test temperature 0 ~ 90 °C± 0.1 °C |
| Needle penetration time | Boot time: 5s, you can set your own |
| Needle penetration range | 0-40mm ± 0.01 mm |
| Time range | 0-60s ±0.1s |
| Total weight of the standard pin and connecting rod | 50g ± 0.05g |
| Weight mass | 50g ± 0.05g |
| Ambient temperature | 5 ~ 40 °C |
| Ambient humidity | ≤ 85% |
| Power supply voltage | 220V |
| Boundary dimension | 330 × 230 × 520mm |
| Power | 600W |
| Weight | 7.2kg |
| Water bath heating power | 1000W |
| Water bath cooling power | 2 × 150W |
| Packaging Detail: | This tester is packed by standard wooden case or as you require |
| Delivery Detail: | 20 days after payment confirmed |
Xi’an Zealchon Electronic Technology Co.,Ltd adhering to the "professional, honest, and providing the best service" business philosophy, with the guidance of professors and researchers from the Well-known institutions in China, developed a series of leading domestic and international standards, Technology class detecting instrument for asphalt and asphalt mixture, Road, bridge deck, geotechnical, structural, etc and OEM designed 12 series more than 100 kinds of laser productswith high power and long service time.
