Scrap Metals Alloy Analyzer can be used to detect the carbon content of chromium in the detection accuracy of 0.03% of the content - for assessment v elocity-promoted corrosion (FAC) of.
It can be used for analysis of iron-based alloys, nickel-based alloys, cobalt based alloys, copper alloys, titanium-based alloys, mixed alloys.
Can accurately identify a variety of complex alloys, such as 304 and 321, P91 and 9 chromium, titanium and titanium seven.
It can be used to identify thousands of different alloy grades. The standard library includes 250 kinds of alloys, the user can customize the 300 kinds of alloys, according to the common name of various alloys, various properties of a unified standard number (UNS), the American Society of Mechanical Engineers number (ASME), and military norms retrieval .
The X3G Knows Metal and Alloys
When you need a reliable analysis tool to provide fast and accurate Positive Material Identification, turn to the X3G. From turnings, shavings,rods, and wires to small parts and components, to more sizeable material or structures, the X3G provides anywhere, anytime testing with faster and more accurate results than ever before.
Elements can be analyzed
Ti, V, Cr, Mn, Fe, Co, Ni, Cu, Zn, Zr, Nb, Mo, Hf, W, Ta, Re, Pb, Ag, Sn, Bi, Sb, and the standard configuration of elements can be
realized advanced customization, user added or modified to suit the use of specific environment.
1.Alloys can be analyzed
Ferroalloy series: stainless steel, chrome / molybdenum alloy steel, low-alloy steel
Nickel-based alloy series: nickel alloys, nickel / cobalt superalloys
Cobalt-based alloy series
Titanium-based alloy series
Copper-based series: bronze, brass, copper-nickel alloy
High temperature alloys: molybdenum tungsten alloy
Aluminum Solutions
2. Metal identification / scrap metal sorting
QA / QC management metal production, processing and manufacturing casting, etc.
Pharmaceutical and biomedical
Cathode material identification, petroleum refining and petrochemical industries
Model: X3G800
Weight: 1.5 kg with batteries
Dimensions: 30cm(L)*23.5cm(W)*9.8cm(H)
Excitation Source: X-ray tube with Ag target; max voltage 50KV
Filters Five (5) available automatic filter positions
Detector: Peltier cooled 10 mm2 Silicon Drift Detector
Power: 2 rechargeable Li-Ion batteries; 6 hours operation per battery; AC adapter is optional
Operating Range: -10°C to 50°C
Computer/Display: with 65,536 colors; back lit; touch screen
Testing Modes Assay and Pass/Fail
Calibrations
Universal (automatically selects proper calibration); Polyethylene plastics; PVC
plastics; Mid-density (glass, ceramics); Alloys; Solders
Data Storage: 16GB standard memory.
Radiation Safety Password protected, No sample (backscatter) shutoff, five minute inactive log-in
Languages Supported: English, Chinese and other 5 languages
Warranty: One year
Standard Accessories
Waterproof Carrying Case
Two (2) Li-ion Batteries
User Interface Guide
Mini USB Cable
316 Stainless Steel Calibration Check Reference Coin
Integrated Wrist Strap
Analyzer Software
replacement warranty:1 year
1. Supplied to visit the factory and study technical training.
2. Support 24-hour technical e-mail.
3. Provide laboratory construction program design guidelines.
4. Provide customized special requirements.
