Specifications
1,Stable inorganic binder material fatigue testing machine price2. Longlife
3. Durable
Mainfeature
-It adopts the tests such as four-point bending, uniaxial compression, Creep springback etc. Under the specified test conditions, it can measure the fatigue life of compaction inorganic binder under repeated load. System supports a variety of test types such as damaged max force, Creep springback, The fatigue stress etc.
-this testing machine is formed by loading system(Including specimen loading fixture), servo ,source, ,Environmental temperature control box, data acquisition and control unit, data analysis software etc.
-Fatigue machine control system do the test of waves such as Sine waves, square wave, Triangle wave, trapezoidal wave to dynamic control of servo valve. Test results draw curve drawing automatically and save the file.
technical parameters
| Technical Parameters | |
| Parameter Names | Details |
| Loading system parameters | |
| Size | length 1250mm×width900mm×height3000mm |
| Servo actuator | 210mm |
| distance of Beam moving up and down | 1000mm |
| Oil cylinder, bar up and down rate | 0.1mm/min~100mm/min |
| Servo actuator maximum output | 200kN |
| displacement | 0~5mm or0~10mm |
| distinguishability | 2μm |
| Accuracy | ±5μm |
| swing | 0.2mm~5mm optional |
| Technical parameters of the servo oil source control system | |
| Size | 1300×1200×1750mm |
| rated working pressure | 21MPa |
| Maximum output flow pump sources | ≥100L/min |
| return pressure | ≤0.5MPa |
| power supply | 380V 50Hz |
| motor power | 37kW |
| Temperature control environment box technology parameters | |
| Size | 1900mm×800mm×2100mm |
| Compressor power | 1.5P |
| Heating power | 400W |
| Internal sizeof environment box | 440×460×830mm |
| Temperature control range | ~20°C~60°C |
| Power supply | 220V 50Hz |
Company Picture
Lab Picture
Certification
Packaging & Shipping
Packaging Details: Wooden Box
Shipping Delivery: Sea & Air Transportation
