18 AWG 2 Core Control Cable - EC-O11002C006
Specifications | |||
Type |
Control Cable |
Issue No. |
6 |
Date of Issue |
2012-6-13 |
Page |
1 |
Application |
|
Control cable is suitable for the interconnection in controlling, signaling, protecting and measuring systems with rated voltages up to and including 450/750V or 0.6/1KV.
|
Component |
Material |
Diameter(mm) |
Inner Conductor |
BC |
1.02*2 |
Insulation |
PVC(red/white) |
1.45 |
Jacket |
PVC, brown, or customized |
0.4(thickness) |
Temperature Rating |
- 30 °C up to + 70 °C (during operation) |
5° C up to +50 °C(during installation) | |
Operating Voltage |
450/750V |
DC Resistance per Conductor @20℃ |
6.32Ohm/1M’Nom. |
Cable allowed bending radius |
Min.6 times of cable Dia. |
