CE list plastic centrifugal pump submersible pump swimming pool pump
Characteristics&use range:
plasticl structures
rust free and anti corrosion
Feature:
SS pump casiSS shaft
Mechanical seal: graphite to ceramic and silicon carbide to silicon carbide
Thermal overload protector in single phase motor
Using single(three) phase power source
complete stainless steel structure
rust free and anti corrosion.
the vortex type or double-vane impeller features
.the maximum solid diameter of passage up to 40mm
standard AISI SS 304 for common acid or alcali (PH value 4-10)
316L for sea water or chemical industry (PH value 0-12)
Model |
capacity m3/h |
head m |
v/hz |
output power kw/hp |
discharge size mm |
NW kgs |
GW kgs |
Packing size mm |
Qty/20" GP |
QDN1.5-30-0.55KWF |
1.5 Max:5 |
30 max:40 |
220V/50Hz 115V/60Hz 127V/60Hz |
0.55kw(3/4 hp) |
50 |
14 |
14.5 |
230*230*540 |
1000 |
QDN1.5-40-0.75KWF |
1.5 Max:5 |
40 max:53 |
220V/50Hz 115V/60Hz 127V/60Hz |
0.75kw/1hp |
50 |
14.5 |
15 |
230*230*570 |
1000 |
QDN1.5-60-1.1KWF |
1.5 Max:5 |
60 max:75 |
220V/50Hz 115V/60Hz 127V/60Hz |
1.1kw/1.5hp |
50 |
16.2 |
16.7 |
230*230*530 |
930 |
QDN1.5-80-1.5KWF |
1.5 Max:5 |
80 max:100 |
220V/50Hz 115V/60Hz 127V/60Hz |
1.5kw/2hp |
50 |
18.5 |
19 |
230*230*720 |
750 |
QDN60/5 |
1.5 Max:6.5 |
40 max:55 |
220V/50Hz |
1.1kw/1.5hp |
40 |
17 |
18 |
230*230*580 |
1000 |
QDN80/7 |
1.5 Max:6.5 |
60 max:75 |
220V/50Hz |
.1.5kw/5hp |
40 |
19.25 |
20.25 |
230*230*700 |
830 |
