Big Capacity Laundry Equipment(laundry Washer,dryer,flatwork Ironer)

Big Capacity Laundry Equipment(laundry Washer,dryer,flatwork Ironer) thumbnail-1
Big Capacity Laundry Equipment(laundry Washer,dryer,flatwork Ironer) photo-1
US$ 3,300 - 10,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
HENGYE
Model Number:
XGQ
Contact Supplier Request Quote Chat Now
Taizhou Hailing District Hengye Machinery Factory
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Jiangsu, China
Brand Name HENGYE
Model Number XGQ

Specifications

big laundry equipment:
1.All computer control,easy operation
2.High efficency,low consumption.
3.Factory botton price.

We supply 15-100Kg washer extractor,tumble dryer,flatwork ironing machine,and we have manufactured these products for several decades.Our products sells in distant markets overseas.



Main Features of washer extractor:

  1. Professional computer control system, excellent capacity and super function, contain of programmable procedures and standard programs, large-screen LCD, and all design in near to human feature.
  2. Mechanical suspension shock structure, low shake, low noise, combination of shock absorbers and springs for maximum absorption, need no excessive foundations.
  3. With a drum without compartment and single door structure convenivent to loading or unloading, and reduces the labor intensity and improves the clean level.
  4. Adopt international famous brand critical components to make sure the stable running, simply and automatic.
  5. High quality stainless steel material is for anti-rust and long-term service. The high quality seal ring is installed at the outer of water liquid .
  6. Advanced frequency inverter and speed-adjusting system, higher washing and extraction efficiency.
  7. Imported precise and durable bearing and framework oil seal, assuring rotary precision and airproof, no leakage.
  8. Multiple sealing system, oil sealing , water sealing, stainless steel sealing.
  9. Built-out bearing lubrication, simple operation, convenient maintenance.
  10. Safety door interlock system, reduce fatigue, misuse and the risk.





Specification:



Model

Unit

XGQ-15

XGQ-30

XGQ-50

XGQ-70

XGQ-100

washing capacity

kg

15

30

50

70

100

Drum volume

L

180

320

544

600

940

Washing speed

r/min

40

38

36

36

32

Middle extract speed

r/min

480

450

400

370

300

High extract speed

r/min

850

800

760

730

700

Motor power

kw

1.5

3

4

5.5

7.5

Converter power

kw

1.2

2.7

3.7

5.2

7.2

Water inlet diameter

Inch

1

1

1

1.25

2

Drain diameter

mm

60

60

76

89

140

Washing time

mins

35-55

35-55

35-55

35-55

35-55

Hot water temprature

°C

70-80

70-80

70-80

70-80

70-80

Compressed air pressure

mpa

/

/

0.4-0.6

0.4-0.6

0.4-0.6

Steam pressure

mpa

/

/

0.3-0.5

0.3-0.5

0.3-0.5

Steam consumption

kg

8

15

20

30

50

Steam lnlet diameter

Inch

1

1

1

1

1

Dimension (mm)

L

1200

1550

1750

1850

1950

W

1200

1550

1750

1850

2100

H

1510

1760

1900

2100

2350

N.W.

kg

950

1900

2600

2800

3200

big capacity laundry equipment(laundry washer,dryer,flatwork ironer)big capacity laundry equipment(laundry washer,dryer,flatwork ironer)big capacity laundry equipment(laundry washer,dryer,flatwork ironer)





big capacity laundry equipment(laundry washer,dryer,flatwork ironer)
