GSM Quad-band Wired Cellular Antenna SMA
US$ 0.9 - 2.5
MOQ: 50 Pieces
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
Mingjin
Model Number:
MJ-GSM-E03
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Magnetic GSM/GPRS Antenna, Magnetic Mount AntennaUS$ 1 - 1.2MOQ: 50 Pieces -
3M Sticker Adhesive GPRS Antenna FME ConnectorUS$ 0.9 - 2.5MOQ: 50 Pieces
-
3G GPRS Data Card External Antenna AerialUS$ 0.9 - 2.5MOQ: 50 Pieces
-
3G UMTS GPRS Antenna Adhesive Bonding SMAUS$ 0.9 - 2.5MOQ: 50 Pieces
-
(factory) Embedded Dual-band Antenna With Ipex/ufl ConnectorUS$ 0.4 - 0.6MOQ: 50 Pieces
Place of Origin
China
Brand Name
Mingjin
Model Number
MJ-GSM-E03
GSM Quad-band Wired Cellular Antenna SMA
|
Model |
MJ-GSM-E03 |
|
Antenna |
Frequency Range |
824~960/1710~2170 |
Polarization |
Vertical |
|
Gain |
2dBi |
|
V.S.W.R |
<2.0 |
|
Impendance |
50Ω |
|
PCB Dimension |
115*22*4mm |
|
Mechanical |
Cable |
RG174 |
Connector |
SMA or others |
|
Radome Material |
ABS |
|
Mounting Method |
Adhesive |
|
Environmental |
Operating Temperature |
-40℃~+85℃ |
Relative Humidity |
Up to 95% |
|
Vibration |
10 to 55Hz with 1.5mm amplitude 2hours |
|
Environmentally Friendly |
ROHS Compliant |
|
WARRANTY: 24 months
