Help CenterMagnetic Adhesive GPS GSM Combo Antenna With FAKRA Connector
Related Products
-
Combined GPS and GPRS/GSM AntennaUS$ 4 - 5MOQ: 50 Pieces -
Hot Sale Combined Combo Gps Gsm Antenna With SMA Male ConnectorUS$ 4 - 5MOQ: 50 Pieces
-
GSM-GPS Combinated AntennaUS$ 4 - 5MOQ: 50 Pieces
-
(factory) GPS/GSM Combination AntennaUS$ 4 - 5MOQ: 50 Pieces
-
(factory)GPS / GSM Multi-Band Through Hole Low Profile AntennaUS$ 4 - 5MOQ: 50 Pieces
magnetic adhesive GPS GSM Combo Antenna
(i)Dielectric Antenna
Center Frequency(MHz):1575.42±3
VSWR:1.5:1
Bandwidth(MHz):±5
Impedance(Ω):50
Peak Gain >3dBi Based on 7cm×7cm ground plane
Gain Coverage >-4dBi at –90°<0 <+90°(over 75% Volume)
Polarization:RHCP
(ii)GSM Antenna
Center Frequency(MHz):850/900/1800/1900
Typical Gain:2dBi+/-1dBi@850MHz ; 2dBi+/-1dBi@900MHz
1dBi+/-1dBi@1800MHz;1dBi+/-1dBi@1900MHz
VSWR:2.0:1
Impedance(Ω):50
(iii)LNA/Filter
LNA Gain (Without Cable) :28 dBi Typical
Noise Figure(dB):1.5
Filter Out Band Attenuation (f0=1575.42 MHz)
7dB Min f0+/-20MHz ;
20dB Min f0+/-50MHz;
30dB Min f0+/-100MHz
VSWR <2.0
DC Voltage(V):2.7/3.0/3.3/5.0/3.0 to 5.0 etc.
DC Current(mA):11 Max
(iv)Mechanical
Weight(gram)<240
Size(mm):Φ80×13
Cable GPS(m):RG174 2,5 etc.
GSM(m):RG174 2,5 etc.
Connector GPS:SMA/SMB/SMC/BNC/FME/TNC/MCX/MMCX etc.
GSM:SMA/SMB/SMC/BNC/FME/TNC/MCX/MMCX etc.
Mounting:Adhesive/Magnetic/Screw(Hole/Roof)
Housing:Black
(v)Environmental
Working Temp:-40℃~+85℃
Storage Temp:-45℃~+100℃
Vibration:Sine sweep1g(0-p)10~50~10Hz each axis
Humidity:Humidity95%~100%RH
Weatherproof:100%Waterproof
