GPS Antenna SMB 90 (Angled) Magnetic Foot
US$ 1.8 - 2.4
MOQ: 50 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Anhui, China
Brand Name:
Mingjin
Model Number:
MJ-GPS-012
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
GPS Panel Antenna 5m SMANegotiableMOQ: 50 Pieces -
Active GPS Antenna With MCX ConnectorUS$ 1.8 - 2.4MOQ: 50 Pieces
-
RG174 Cable 3m Fakra Gps AntennaUS$ 2.55 - 2.95MOQ: 50 Pieces
-
Gps External Antenna, Gps Active Antenna, 1575 Gps AntennaUS$ 0.4 - 0.6MOQ: 50 Pieces
-
3m RG174 Cable Sma, Sma Gps Active Antenna, Sma Gps, Sma Gps AntennaUS$ 2 - 2.9MOQ: 50 Pieces
Place of Origin
Anhui, China
Brand Name
Mingjin
Model Number
MJ-GPS-012
GPS Antenna SMB 90 (Angled) Magnetic foot
| Model | MJ-GPS-012 |
|
Antenna |
Center Frequency |
1575.42±1MHz |
Band Width |
CF±5MHz |
|
Polarization |
RHCP |
|
Gain |
5dBic(Zenith) |
|
V.S.W.R |
<1.5 |
|
Impendance |
50Ω |
|
Axial Ratio |
3dB(max) |
|
Dimension |
35*39*14mm |
|
LNA |
Gain |
28±2dB |
Noise Figure |
<1.5 |
|
Filter Insertion Loss |
<3dB |
|
Ex-band Attenuation |
12dB@CF+50MHz/16dB@CF-50MHz |
|
Supply Voltage |
2.2~5V DC |
|
Current Consumption |
5~15mA |
|
V.S.W.R |
<2.0 |
|
Mechanical |
Cable |
RG174 |
Connector |
SMA |
|
Radome Material |
ABS |
|
Mounting Method |
Magnet/Adhesive |
|
Environmental |
Operating Temperature |
-40℃~+85℃ |
Relative Humidity |
Up to 95% |
|
Vibration |
10 to 55Hz with 1.5mm amplitude 2hours |
|
Environmentally Friendly |
ROHS Compliant |
|
