Help CenterNHXMH Cable
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
1999
Factory Size:
50,000-100,000 square meters
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Specifications
NHXMH Cable- Application:
- These cables ( NHXMH )are intended for fixed installation in dry and moist rooms as well as in masonry and concrete, in and under plaster; not for underground installation.NHXMH-J/O are especially used in buildings with a high concentration of persons or valuable property, where improved fire characteristics are needed. This product
conforms to 73/23/EW G directive (low voltage directive) CE. - Standards: VDE 0250 (part 214), VDE 0482 (part 266-2-4, test type C)
-
Conductor: - Class 1 for re: round solid plain copper conductor, single wire to VDE0295
Class 2 for rm: round stranded plain copper conductor, multi wire to VDE0295
Class 2 for sm: sectorial stranded plain copper conductor to VDE0295 -
Insulation:XLPE (Cross-linked Polyethylene)
-
Filler: Halogen free compound
-
Sheath: XLPE (Cross-linked Polyethylene)
-
Sheath Colour:White
-
Voltage Rating:300/500V
-
Temperature Rating:0°C to +70°C
-
Minimum Bending Radius: 4 x overall diameter
- Core Identification:
- Up to and including 5 cores: colour coded or number coded
7 cores and above: number coded
| No. of Cores x Nominal Cross Sectional Area# x mm² | Stranded Conductor Type | Nominal Overall Diametermm |
|---|---|---|
| 1 x 1.5 | re | 7.0 |
| 1 x 2.5 | re | 7.6 |
| 1 x 4.0 | re | 8.6 |
| 1 x 6.0 | re | 9.9 |
| 1 x 10.0 | re | 11.2 |
| 1 x 16.0 | re | 11.9 |
| 2 x 1.5 | re | 8.9 |
| 2 x 2.5 | re | 10.0 |
| 2 x 4.0 | re | 11.4 |
| 3 x 1.5 | re | 9.4 |
| 3 x 2.5 | re | 10.4 |
| 3 x 4.0 | re | 11.8 |
| 3 x 6.0 | re | 13.4 |
| 3 x 10.0 | re | 16.0 |
| 3 x 16.0 | re | 19.7 |
| 3 x 25.0 | rm | 24.3 |
| 3 x 35.0 | sm | 27.2 |
| 4 x 1.5 | re | 10.2 |
| 4 x 2.5 | re | 11.3 |
| 4 x 4.0 | re | 13.3 |
| 4 x 6.0 | re | 14.8 |
| 4 x 10.0 | re | 17.4 |
| 4 x 16.0 | re | 21.6 |
| 4 x 25.0 | rm | 27.0 |
| 4 x 35.0 | sm | 29.9 |
| 5 x 1.5 | re | 10.8 |
| 5 x 2.5 | re | 11.9 |
| 5 x 4.0 | re | 14.8 |
| 5 x 6.0 | re | 16.0 |
| 5 x 10.0 | re | 18.9 |
| 5 x 16.0 | re | 23.8 |
| 5 x 25.0 | rm | 29.0 |
| 5 x 35.0 | rm | 32.7 |
| 7 x 1.5 | re | 11.4 |
| 7 x 2.5 | re | 13.5 |
| |
