XK-W313 BENDING TESTING MACHINE TEACHING EQUIPMENT
PRODUCT INTRODUCTION
1 The bending test machine is dedicated to metal flexural teaching test. Using the increase or decrease in the hanging weight, the load on the specimen, using precision dial gauge shows the specimen deformation. It is easy to operate, can the relationship between the more intuitive reflect the bending moment and bending.
2 This product is mainly composed of steel and aluminum alloy processing into the frame body and the dial gauge, 100200 500g weight.
TECHNICAL PARAMETER
The maximum sample length: 700mm;
Reverse weight: 100g, 200g, 500g, two; weight tray: 200g, accuracy of 0.1% (step adjustable); weight bracket;
Sample size: 30 × 700;
Effective Testing space: 600mm;
Overall dimensions of approximately: 810 * 240 * 600mm
Weight approximately: 20KG
TRAINING FUNCTION
1 The device by the framework, the mobile beam (sample installation beam), dial indicator, dial indicator bracket load weight, the weight tray and other component parts.
2 Three linear axes and two fixed steel plate bearing framework, constitute the main part of the testing machine.
3 Move the beam into two structures, are free to convenient adjustment of the locking screw locking.
4 Move the beam upper part of the curved support plate of heat treatment used to support the specimen.
Precision dial gauge for bending test specimens and the bracket can be easily adjusted.
5 The weights used for load moment, step by step configuration.
6 The whole beautiful shape, easy to operate.
