Electrical Trainer Electrical Lab Electrical Technology Training Syst XK-ETT2 Double-Station Electrical Technology Training Sets
1. Product Overviews:
XKETT2 will finish the electrician assessment for the lighting circuit,motor control,electric power meter. It adopts stainless steel web board structure; components dismounting convenient, easy for organize experiments, convenient for extension and upgrade.
Below of the bench equipped with required kinds of signal sources and kinds of electric power meter
Bench equipped with mobile wheels, desktop is high density fireproofing,waterproofing board.
XK-ETT2 power supply equipped with leakage protection,short circuit protection etc to ensure the safety.
2. Experiment Bench Technology Parameter:
2.1 Product Size: 1500mm × 650mm × 1600mm
2.2 Power Supply: the three-phase AC380V, power < 1000 VA
2.3 Three phase power source main switch with leakage protection
2.4 With emergency stop button etc. and power indication light,power supply indication
3. Accessories for training bench
3.1 Relay contact components, including: fuse with seat,contactor,intermediate relay,time relay,thermal relay,button,indicator light,trunking,guide rail,wiring terminals,flexible wire,light switch,incandescent light bulb and seat
3.2 Three phase synchronous motor: 1 set
3.3 Manual: 1pcs
4. Experiment Projects
Three-phase induction motor direct start control
Three-phase asynchronous motor contactor control circuit jog
Three-phase-phase asynchronous motor contactor control circuit self-locking
Three-phase-phase asynchronous motor contactor jog control circuit with self-locking
Three-phase-phase asynchronous motor reversing control circuit interlock button
Three-phase asynchronous motor reversing contactor interlock control circuit
Three-phase asynchronous motor button reversing contactor double interlock control circuit
Three-phase asynchronous motor manual sequential control
Three-phase asynchronous motor automatic sequence control
Multi-phase asynchronous motor control
Three-phase asynchronous motor Y-DELTA starter manual control lines
Three-phase asynchronous motor Y-DELTA starter automatic control circuit
Single-button control of the motor start-stop experiment
Experimental phase motor reverse braking
Motor timer operation control experiments
Incandescent experimental installation
Two switches control one light experiment
Single-button controls two lights were lit experiment
Time relay control two bright lights cycle experiment
Three bright lights cycle experiment
