Window System PVC Profile Mould
Product Description
Product name: Window System PVC Profile Mould |
|
|
| ||
Mould material: |
Professional and technical high abrasion treatment. |
|
Mould component: |
Vacuum eddy current stereotypes tank,Calibrator,Die. |
|
Mould cavity: |
single or multi. |
|
Mould surface treatment: |
High polished surface. |
|
Profile material: |
PVC.PE.PP.WPC |
|
Extrusion speed: |
3-7 meter per minute |
|
Package: |
Wooden case, |
|
Lead time: |
20-30 days |
|
Production ability: |
60sets moulds per month |
|
Main Market: |
Southeast Asia,Europe,Africa,etc. |
|
Test service: |
Mould will be tested to get the satisfy sample before deliver. |
|
Feature: |
High speed production,High wear resistance,Good stability. |
|
| ||
Characteristics: |
easy operation,wonderful after-sale service,high line speed,long-life using. |
|
1. Full range of specifications: floor, wall, ceiling, guardrail, door and window series etc.
2. High-quality,high speed,high precision molds and reasonable prices.
3. The wood-plastic molds feature fine wood texture and environmental protection.
4. Different PVC,PE,PPR,ABS,Pc and other plastic pipe mould, wpc wood plastic composite
5. We can provide a whole set to technical support including extruder election,formulas process and extrusion mould.
The PVC profile extrusion mould die head design:
Use the removable positioning device, making it easier to disassemble.
Precise material flow control and stable extrusion.
The hidden heating design has increased the brightness of the product surface.
The special balance of the pressure holes has lowered the rejection rate.
The PVC profile extrusion mould calibrator design :
The automatically adjusting positioning key gives it a precise size
The tapered design of the styling sets has increased the production speed greatly.
The inlet end is independent vacuum and shapes well.
The camber adjusting device ensures that the line is straight.
Extrusion cooling design for pvc profile mould :
Double vacuum system promotes the molding.
The combination design of eddy current and spray makes it cools fast..
The self-adjusting water tank panels are easy to adjust.
The stainless steel frame type system can prevent damage.
The special influent distribution gives it a cooling balance.
WE CAN DO:
.Mould/Extrusion Tooling/Extrusion Dies of PVC and foam inside
.Mould/Extrusion Tooling/Extrusion Dies of PE/PP and wood powder(chaff powder, sawdust, and wheat straw pole etc)
. Low foaming PVC profiles die/Extrusion Tooling/Extrusion Dies, decoration profiles extrusion moulds/Extrusion .
.Tooling/Extrusion Dies
. Hard PVC entire plank door, sheet material, plank material mould /Extrusion Tooling/Extrusion Dies
.Steel- plastic coextrusion and aluminum-plastic composite coextrusion mould /Extrusion Tooling/Extrusion Dies
. Various pipe material and porous communication pipe mould/Extrusion Tooling/Extrusion Dies
our mould:
PVC Window and Door Profile Mould Type: 80 series window profiles, 60 series window profiles, casement window profiles, sliding window profiles, ect. PVC window profile designs and samples could be provided.
Hubei TianRui Plastic Mould Co., Ltd is a professional plastic profile extrusion mould manufacturer with 3000 square meters workshop and 60 skilled technical workers. Hubei Tianrui Company has accumulated over 18 years of experience in the technology of extrusion mould. From mould designing, production to commissioning, we have cultivated a mature team of personals to garantee the extrusion mould quality.
Hubei TianRui Plastic Mould Co., Ltd is a professional pvc profile extrusion mould manufacturer with 3000 square meters workshop and 60 skilled technical workers. Hubei Tianrui Company has accumulated over 18 years of experience in the technology of extrusion mould. From mould designing, production to commissioning, we have cultivated a mature team of personals.
