DEUTZ Water-cooled Diesel Genset

Name: DEUTZ Water-cooled Diesel Genset
Brand: BOBIG
SKU: 109129331
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Fujian, China

Brand Name:

BOBIG

Model Number:

GF2-100

Fujian Bobig Electric Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

FUZHOU

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Fujian, China

Brand Name BOBIG

Model Number GF2-100

Output Type AC Three Phase

Speed 1500RPM/1800RPM

Frequency 50HZ/60HZ

Rated Power 100KW

Rated Voltage 400V/230V

Rated Current 180AH

Specifications

DEUTZ water-cooled diesel genset
1.Deutz engine
2.Copy stamford alternator
3.Brushless excitation
4.Watercool

DEUTZ water-cooled diesel genset

Model		GF2-100
ENGINE	Engine Model	TBD226B-6D
	Rated Output(KW)	120
	Max Output(KW)	132
	Starting method	Electric starting
	Cooling method	Closed water cooled
	Governing method	Mechanical
	Intaking method	Natural apirated
	Cylinder numbers	6
	Fuel consumption(g/kw.h)	≤205
	Bore/stroke(mm)	105/120
	Displacement(L)	6.23
	Oil volume(L)	13
	Type	Water cooling, in-line, four-stroke, humid cylinder liner,direct injection
	Crankshaft rotation direction	Counterclockwise(face to output end)
ALTERNATOR	Model	274D
	Rated Output(KW)(KVA)	100(125)
	Rated Voltage(V)	400/230
	Rated Current(A)	180
	Frequency(HZ)	50/60
	Power Factor	0.8 lagging
	Phase/Connection	3-phase 4-wire Y-type connection
	Excitation	Harmonic or Brushless Excitation
	Voltage Regulation	Manual/Automatic
Net Weight(kg)		1450
Packing Size LWH(cm)		25090185
