110kw Hot Sale BOBIG Water Cooled Diesel Generator set powered by Lovol
Negotiable
/ Set
1 Set(Min.Order)
- 3000 Set / Sets per Month
- FUZHOU
- T/T
You May Like
Product Details
Place of Origin: | Fujian, China | Brand Name: | BOBIG | Model Number: | BL150 BL150S |
Speed: | 1500RMP | Frequency: | 50HZ | Rated Power: | 24 |
Rated Voltage: | optional |
Product Description
Diesel Generator 100kva generator LOVOL water cooled engine from 24kw to 110KW
Specifications
OEM,LOVOL 100kva generator
1.Original LOVOL generator engine
2.original stamford 100kva generator
3.CE,ISO9001
1) Output range: 24KW - 110kW diesel generator set |
2) Engine model: 1003G,1003TG,1004G,1004TG,1006TG3A,1006TG2A,1006TAG |
3) Alternator: Stamford, Leroy Somer, Marathon series |
4) Water-cooled |
5) 8hrs operation base tank |
6) Key start / auto start |
7) Sound-proof / weather-proof canopy is optional |
8) 230 / 400V AC, 50Hz / 60Hz, 0.8pF three-phase and four wires alternating current output |
9) Frequency: <3% |
10) Frequency at stable state: <0.5% |
11) Frequency deviation at instantaneous state: ≤+10% |
12) Frequency return time: ≤3s |
13) Voltage deviation at stable state: ≤+ -1% |
14) Voltage deviation at instantaneous state: ≤+20% |
15) Voltage return time: ≤4s |
16) Voltage modulation: ≤0.3% |
17) Standard configuration of gensets: |
A) Engine: LOVOL diesel engine diesel generator set |
B) Engine type: Water-cooled, in line four-stoke, dry cylinder liner, direct injection |
C) Alternator: Brushless and "H" class insulation |
18) Control system: |
A) Automatic alarm system: The unit has the acousto-optics alarm system and |
Arrestor for any situation as the start defeat, the water is over temperature, |
The oil pulls down, over speed, over load and over current |
B) Operation display: |
I) Unit voltage, tri-phase load current and frequency display |
Ii) Water temperature, oil pressure display |
Iii) Fuel level, fuel temperature display |
Iv) Audible and visual alarm lamps and buzzers |
19) Starting system: DC alternator is used to start engine |
20) Short circuit protection: MCCB air switch |
21) Cooling system: Combined cooling water tank fitted to meet the requirement of radiation at ambient temperature 40 degree |
22) Filter system: Oil, fuel and air filter |
23) Accessories: Exhaust elbow, bellow, muffler |
24) Supply standard collocation: |
A) Diesel engine with all accessories, 3 filter, electric systems |
B) Alternator |
C) Steel structure |
D) Fan and water tank cooling system |
E) Flange connector |
F) 12 / 24V starting motor and charge engine |
G) Air cleaner, fuel cleaner, oil cleaner |
H) On-board control panel |
Warranty:Guarantee for one year or 1200hours from ex-factor date.During the repair time,BOBIG COMPANY will provide the free easy-damageable spare arts of diesel engine caused by our quality of production or raw material.After expiration,BOBIG COMPANY will supply cost spare part for you to repair it. |
Manufacturing standard: |
ISO9001,EPA,CE and ....... |
For more detail information,pls feel free to contact with us. |
Contact : Linda Zheng
mobile/Whatsapp : +86 13960835596
Skype: lindazheng50
QQ:1020162161
