Related Products
Specifications
Generatora. Engine:Deutz, Cummins, Perkins
b. Power 8-800kw
c. Alternator: Stamford, Leroy Somer
Generator
Detailed Product Description
Features:
1) Rated output:8-800kw
2) Rated voltage: 400 / 230V, 380 / 220, 220 / 120
3) Rated frequency: 50 / 60Hz
4) Power factor: 0.8
Genset for protection:Low oil altert and shutdown,overspeed( overload) alert and shutdown,high water temperature alert and shutdown, others.
Genset standard configures:
1) Genuine engine,
2) Alternator,
3) Water tank,
4) Base fuel tank,
5) Storage battery(24V),
6) Automatic control panel,
7) Multifunctional display,
8) Controller,
9) Accessary
Optional accessories: Engine coolant and oil heater, alternator space heater, cooling for heat exchanger, communication interface, battery charger by main supply, daily fuel tank, ATS and paralleling system, moving trailer.
Guarantee for one year or 1000 hours whichever reach first from ex-factory date. During the guarantee period, Youth will provide the free easy-damageable spareparts of diesel engine caused by our quality of production or raw material. After expiration, Youth provides cost spare parts maintenance of gensets.
Engine: Deutz, Cummins, Perkins
1)Cooling method: closed water cooling
2)Starting method: electric start
3)Rated speed: 1,500 / 1,800rpm
Alternator:
1) Brand: Stamford or Leroysomer or Our BOBIG series
2) Rated output:24-120KW
3) Rated voltage: 400 / 230V
4) Rated Frequency: 50 / 60Hz
5) Power factor: 0.8
6) Phase: 3-phase, 4-wire
7) Connection: Y or other type connection
8) Rated speed: 1,500rpm / 1,800rpm
9) Excitation: harmonic excitation or phase compound or brushless
11) Voltage regulation: automatic
12) 1.0% voltage regulation (max.) in static conditions
13) Protection class: IP 22 or IP23
Control panel:
The panel is provided with:
a) Standard engine instrumentation
b) Voltmeter with selector switch
c) Ammeter with selector switch
d) Frequency meter
e) Current transformers
f) Instrument fuses duly wired and ferruled
g) Mcb of suitable rating with overload and short circuit protection
h) With AMF control panel or with ATS (automatic transfer system)
