Power Generator

Specifications

power generator

Detailed Product Description
Features:
1) Rated output: 20-536KW

2) Rated voltage: 400 / 230V, 380 / 220, 220 / 120
3) Rated frequency: 50 / 60Hz
4) Power factor: 0.8

Engine:
1)Cooling method: closed water cooling
2)Starting method: electric start
3)Rated speed: 1,500 / 1,800rpm

Alternator:
1) Brand: Stamford,Leroysomer, Copy stamford,etc

2) Rated output: 20-536KW
3) Rated voltage: 380,400,415/200,208,220v
4) Rated Frequency: 50 / 60Hz
5) Power factor: 0.8
6) Phase: 3-phase, 4-wire
7) Connection: Y or other type connection
8) Rated speed: 1,500rpm / 1,800rpm
9) Excitation: harmonic excitation or phase compound or brushless
11) Voltage regulation: automatic/manual
12) 1.0% voltage regulation (max.) in static conditions
13) Protection class: IP23

Control panel:
The panel is provided with:
a) Standard engine instrumentation
b) Voltmeter with selector switch
c) Ammeter with selector switch
d) Frequency meter
e) Current transformers
f) Instrument fuses duly wired and ferruled
g) Mcb of suitable rating with overload and short circuit protection
h) With AMF control panel or with ATS (automatic transfer system)
