Specifications
EPA approved diessel generatorscummins engine,silent type
original stamford generator
3-phase,4 wire
CE, ISO9001
EPA approved diessel generators
THE BRAND OF ENGINE:Cummins ENGINE(FAMOUS IN The world)
Specification:
1) Rated output: 20KW/25KVA
2) Rated voltage: 400 / 230V, 380 / 220, 220 / 120
3) Rated frequency: 50 / 60Hz
4) Power factor: 0.8.
Engine: Cummins engine
1)Cooling method: closed water cooling or air force cooled
2)Starting method: electric start.
3)Rated speed: 1,500 / 1,800rpm
4) Noise level: 65dB to 75dB 7 meter away
Alternator:
1) Brand: Stamford or Leroysomer or Our BOBIG series
2) Rated output: 20 -1000kW / 25kVA -1250kVA
3) Rated voltage: 400 / 230V according to your requested
4) Rated Frequency: 50 / 60Hz
5) Power factor: 0.8
6) Phase: 3-phase, 4-wire
7) Connection: Y or other type connection
8) Rated speed: 1,500rpm / 1,800rpm
9) Excitation: harmonic excitation or phase compound or brushless
11) Voltage regulation: automatic
12) 1.0% voltage regulation (max.) in static conditions
13) Protection class: IP 22 or IP23
14)Connect with engine:Direct coupled with flywheel
Control panel:
1) The generator control panel is manufactured locally by
2) The panel is provided with:
a) Standard engine instrumentation
b) Voltmeter with selector switch
c) Ammeter with selector switch
d) Frequency meter
e) Current transformers
f) Instrument fuses duly wired and ferruled
g) Mcb of suitable rating with overload and short circuit protection
h) With AMF control panel or with ATS (automatic transfer system)
i) With EPA certification
Packing:
Wooden case or plywood case
Remark:Control panel(including Automatic protection):low and high frequency,low oil pressure protection and high water temperature protection
Synchronization panel is available at our factory.
Warranty:Guarantee for one year or 1200hours from ex-factor date.During the repair time,BOBIG COMPANY will provide the free easy-damageable spare arts of diesel engine caused by our quality of production or raw material.After expiration,BOBIG COMPANY will supply cost spare part for you to repair it.
Manufacturing standard:
ISO9001,EPA,CE and .......
For more detail information,pls feel free to contact with us.
To know a real BOBIG factory:
Please Check our Factory Audit Report by BV
(you can download the report from our homepage)
