Yangdong Engine Diesel Generator
USD $999 - $9,999
/ Unit
1 Unit(Min.Order)
- 500 Unit / Units per Month
- Fuzhou Ningbo Shanghai
- T/T Credit Card
You May Like
Product Details
Place of Origin: | Fujian, China | Brand Name: | BOBIG | Model Number: | GF |
Output Type: | AC Three Phase | Speed: | 1500/1800RMP | Frequency: | 50/60HZ |
Rated Power: | 8kw to 30kw | Rated Voltage: | 230 240 220/127V 400/230V 380/220V | Rated Current: | 14.4A |
Product Description
Specifications
Yangdong Engine Diesel Generator1.Brushless alternator
2.Yangdong engine
3.EPA approved
4.silent or open
Yangdong Engine Diesel Generator
Bobig-yangdong series
Model | GF-8 | GF-10 | GF-12 | GF-15 | GF-20 | GF-25 | GF-30 | ||||||||
GENERATOR | Type | alternator | |||||||||||||
Frequency Hz | 50/60hz | ||||||||||||||
Cont.AC output Kw | 8 | 10 | 12 | 15 | 20 | 25 | 30 | ||||||||
Voltage V | 220~240 220~240/110~120 400/230V | ||||||||||||||
Power factor | 0.8 | ||||||||||||||
Excitation system | Self-excitation | ||||||||||||||
ENGINE | Model | YSAD380 | Y385 | YD480 | YD485 | YSD490 | K4102D1-1 | K4102D1-1 | |||||||
Number of cylinders | 3 | 3 | 4 | 4 | 4 | 4 | 4 | ||||||||
Displacement L | 1.357 | 1.532 | 1.809 | 2.043 | 2.54 | 3.76 | 3.76 | ||||||||
Bore×stroke mm | 80*90 | 85*90 | 80*90 | 85*90 | 90*100 | 102*115 | 105*115 | ||||||||
Rated speed(r/min) | 1500 | 1800 | 1500 | 1800 | 1500 | 1800 | 1500 | 1800 | 1500 | 1800 | 1500 | 1800 | 1500 | 1800 | |
Cont.output kW | 10.0 | 11.0 | 11.0 | 12.6 | 13.2 | 15.8 | 15.0 | 18.0 | 21.0 | 25.0 | 33.0 | 39.0 | 33.0 | 39.0 | |
Max.outout kW | 11.0 | 12.0 | 12.0 | 13.8 | 14.5 | 17.5 | 16.5 | 20.0 | 23.0 | 27.5 | 36.0 | 43.0 | 36.0 | 43.0 | |
Starting system | Electric | ||||||||||||||
Cooling method | Closed/Open circle water-cooied | ||||||||||||||
Starting battery | 12V120AH | ||||||||||||||
Firing order | 1-3-2 | 1-3-2 | 1-3-4-2 | 1-3-4-2 | 1-3-4-2 | 1-3-4-2 | 1-3-4-2 | ||||||||
Compression Ratio | 22.5 | 22 | 18 | 18 | 18 | 19 | 19 | ||||||||
Specific fuel consumption (g/kW.h) | ≤247 | ≤262.5 | ≤250.2 | ≤247 | ≤247.5 | ≤258 | ≤258 | ||||||||
DIMENSIONS | Fuel tank capacity L | 100 | |||||||||||||
ing timeh | 45 | 35 | 32 | 25 | 20 | 15 | 12 | ||||||||
Overall dimensions (L×W×H) mm | 1800*850*1000 | ||||||||||||||
Package dimensions (L×W×H) mm | 1850*900*1050 | ||||||||||||||
Net weight kg | 610 | 630 | 650 | 700 | 780 | 1100 | 1150 | ||||||||
Dry weight kg | 640 | 670 | 680 | 730 | 810 | 1130 | 1180 |
Warranty: we offer one year or 1500 hours to our engine and alternator. During these period, provide spare parts for free,but air filter, oil filter or some parts which are easy to consume is not included.
