Home > Electrical & Electronics > Telecommunication & Broadcasting > Fiber Optic Equipment > GEPON ONU With 4 FE Ports and Wi-Fi GONU1000W

GEPON ONU With 4 FE Ports and Wi-Fi GONU1000W

Name: GEPON ONU With 4 FE Ports and Wi-Fi GONU1000W
Brand: Greatwaytech
SKU: 109117671
Availability: InStock

GEPON ONU With 4 FE Ports and Wi-Fi GONU1000W thumbnail-1

GEPON ONU With 4 FE Ports and Wi-Fi GONU1000W thumbnail-2

GEPON ONU With 4 FE Ports and Wi-Fi GONU1000W thumbnail-3

GEPON ONU With 4 FE Ports and Wi-Fi GONU1000W thumbnail-4

GEPON ONU With 4 FE Ports and Wi-Fi GONU1000W photo-1

GEPON ONU With 4 FE Ports and Wi-Fi GONU1000W photo-2

GEPON ONU With 4 FE Ports and Wi-Fi GONU1000W photo-3

GEPON ONU With 4 FE Ports and Wi-Fi GONU1000W photo-4

US$ 40.00 - 40.00 MOQ: 1 Set

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

Greatwaytech

Model Number:

GEPON ONU GONU1000W

Contact Supplier Request Quote Chat Now

Shenzhen Greatway Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHENZHEN

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name Greatwaytech

Model Number GEPON ONU GONU1000W

Product Description

GEPON ONU with 4 FE ports and Wi-Fi GONU1000W

Feature
l Support port-based rate limitation and bandwidth control;
l In compliant with IEEE802.3ah Standard
l Up to 20KM transmission Distance
l Support data encryption, group broadcasting, port Vlan separation, RSTP etc.
l Support Dynamic Bandwidth Allocation (DBA)
l Support ONU auto-discovery/Link detection/remote upgrade of software;
l Support VLAN division and user separation to avoid broadcast storm;
l Support power-off alarm function, easy for link problem detection
l Support broadcasting storm resistance function
l Support port isolation between different ports
l Support ACL and SNMP to configure data packet filter flexibly
l Specialized design for system breakdown prevention to maintain stable system
l Support software online upgrading
l EMS network management based on SNMP, convenient for maintenance

Specification

Item	Parameter
PON Interface	1 GEPON optical interface Meet 1000BASE-PX20 standard Symmetric 1.25Gbps upstream/downstream SC single-mode fiber split ratio and distance: 1:64/10Km, 1:32/20Km
User Ethernet Interface	4*10/100Mauto-negotiation Full/half duplex mode RJ45 connector Auto MDI/MDI-X 100m distance
PON Optical Parameter	Wavelength: Tx 1310nm, Rx1490nm Tx Optical Power: -1~4dBm Rx Sensitivity: -24dBm Saturation Optical Power: -3dBm Connector Type: SC/UPC Optical Fiber: 9/125m single-mode fiber
Data Transmission Parameter	PON Throughput: Downstream 950Mbps; Upstream 930Mbps Ethernet: 100Mbps Packet Loss Ratio: <1*10E-12 latency: <1.5ms
Business Capability	Layer 2 wire speed switching Support VLAN TAG/UNTAG, VLAN conversion Support Port-based speed limitation Support Priority classification Support storm control of broadcast Support RSTP
Network Management	Support IEEE802.3 QAM ONU can be remotely managed by OLT Support Remote management through SNMP and Telnet Local management
Management Function	Status monitor, Configuration management, Alarm management, Log management
LED Indicator	PWR: Power up or down OPTIN: Optical Link Status LINK: ONU Registered ETH: Link Status of Ethernet Interface LAN: Link Status of Ethernet Interface WIFI: WIFI status
Shell	Plastic casing
Power Supply	External 12V 0.5A AC/DC power supply adapter Power consumption: < 3.8W
Physical Specifications	Dimension: 160mm(L) x 120mm(W) x 30mm (H) Weight: 0.2kg
Environmental Specifications	Operating temperature: 0 to 50ºC Storage temperature: -40 to 85ºC Operating humidity: 10% to 90%(Non-condensing) Storage humidity: 5% to 95% (Non-condensing)
