GONU1000 is a cost-effective GEPON customer premise device designed for indoor residential and Single Office/Home Office (SOHO) installation. It supplies Gigabit broadband service to a connected subscriber’s gateway or computers. GONU1000 provides one 10/100/1000M Ethernet port or four 10/100M Base-T Ethernet ports with advanced L2 functionality for Data and IPTV video services.
FEATURES
• Full IEEE 802.3/802.3ah compliance
• Single fiber for Data communication
• High speed PON: 1 Gbit/s symmetrical data
• “Plug-and-play” via auto-discovery and configuration
• Advanced QoS functions
• Remote management with advanced OAM functions
• Secure access via Access Control List (ACL)
• Advanced L2 Function: IGMP Snooping, VLAN, MAC address Management
Specifications:
Optical Link Performance | |
Optical Fiber |
Single Mode |
Fiber Connector |
SC/UPC |
Optical Return Loss |
45dB |
Output Power at 1310nm |
-1~ +3 dBm |
Receiving Sensitivity at 1490nm |
-24 dBm |
Wavelength |
TX: 1310 nm RX: 1490 nm |
Ethernet | |
Data Rate |
1Gbps uplink and downlink |
Maximum Splitting |
1:32 (20Km fiber reach) 1:64 (10Km fiber reach) |
Ethernet Port |
One 10/100/1000Mb/s Port or Four 10/100Mb/s RJ-45 Ports |
Ethernet Cable |
CAT-5 or CAT-6 (100 m) |
Standards |
IEEE 802.3ah IEEE 802.1p 802.1Q 802.1d 802.1w IEEE 802.3ad |
Management |
Embedded OAM Protocol, SNMP, Remote software upgrading |
Environment | |
Working Temperature |
- 5 ºC ~ 55 ºC |
Storage Temperature |
-40 ºC ~ 80 ºC |
Humidity |
5% ~ 95% Non-condensing |
RoHS |
Compatible |
Physical | |
Weight |
1Kg |
Power Supply | |
Power |
12V 1A DC Adaptor, UL or CE certified |
Power Consumption |
<6 W |
Ordering Information:
GONU1000-X GEPON ONU
X(Ethernet Ports): None_one 10/100/1000Mb/s port; 4_four 10/100Mb/s ports
