Main Product: diesel engine, diesel generator, alternator and spare parts;
Diesel Engine Usage: Widely used for generator set, boat, wheel loader, truck, water pump, sand pump,
fire pump, construction machine, etc;
Diesel Engine Power Range: from 20kw up to 700kw;
Diesel Generator Power Range: from 30kw up to 700kw.
Chinese Generator Plant Silent type Diesel Genset 160kw Technical Parameters
Genset Model (LD Brand) |
LD150GF | LD160GF | |
| Rated Power/Speed kw/r/min | 150/1500 | 160/1500 | |
| LD Diese Engine | Engine Model | LD6LA245L | LD6LA265L |
| Rated Power/Speed kw/r/min | 165/1500 | 176/1500 | |
| Type | Vertical,inline, water-cooled, four stroke | ||
| Intake Way | Turbocharged & Inter-cooled |
||
| Number of cylinders×bore×stroke (mm) | 6-108×140 | ||
| Total displacement(L) | 7.7 | ||
| Min fuel consumption (g/kw.h) | ≤195 | ||
| Starting type | Electric | ||
| Speed governor model | Electric | ||
| Oil capacity(L) | 18-20 | ||
| Low noise limit dB (A) | ≤102 | ||
| Wattek Alternator (Stamford Technology) | Alternator model | 274G | 274H |
| Rated voltage (V) | 400/230 or 380/220 | ||
| Current( A) | 270 | 288 | |
| Freq( Hz) | 50 or 60 |
||
| Regulator approach | AVR | ||
| Power factor (CosØ) | 0.8 Lagging | ||
| Phase | 3Phase 4Wire | ||
| Insulation Class | F / H | ||
| Protection Class | IP22 / IP23 | ||
| Genset Packing | Net weight (kg) | 1800 | 2200 |
| Genset Dimention(LxWxH)mm | 3300x1200x1550 | ||
LD Diesel Generator Models for Option:
|
Gen-set Model |
3-PHASE, 4-WIRE | Model | |||
| Prime Power | Engine | Alternator | Controller | ||
| kw | kva | LD Brand | WATTEK | SMARTGEN | |
| LD30GF | 30 | 37.5 | LD4F50 | 184H | 6120 |
| LD40GF | 40 | 50 | LD4F65Z | 224D | 6120 |
| LD50GF | 50 | 62.5 | LD4D85Z | 224E | 6120 |
| LD60GF | 60 | 75 | LD4D110L | 224F | 6120 |
| LD80GF | 80 | 100 | LD6B135Z | 274C | 6120 |
| LD100GF | 100 | 125 | LD6B170L | 274D | 6120 |
| LD120GF | 120 | 150 | LD6B210L | 274E | 6120 |
| LD150GF | 150 | 188 | LD6LA245L | 274G | 6120 |
| LD160GF | 160 | 200 | LD6LA265L | 274H | 6120 |
| LD180GF | 180 | 225 | LD6LA285L | 274J | 6120 |
| LD200GF | 200 | 250 | LD6LM350L | 274K | 6120 |
| LD250GF | 250 | 312.5 | LD6M420L | 444D | 6120 |
| LD300GF | 300 | 375 | LD6MK510L | 444FS | 6120 |
| LD360GF | 360 | 450 | LD6MJ570L | 544 | 6120 |
| LD400GF | 400 | 500 | LD12M690L | 544C | 6120 |
| LD468GF | 468 | 585 | LD12M750L | 544E | 6120 |
| LD500GF | 500 | 625 | LD12MJ840L | 544FS | 6120 |
| LD600GF | 600 | 750 | LD12MJ1020L | 634B | 6120 |
Chinese Generator Plant Silent type Diesel Genset 160kw Warranty Service
1.Warranty iterms will be issued by our own factory, which is simple and quick;
2.Warranty period will be 12 monthes or 1500 working hours from commissioning date;
3.Parts replacement under warranty will be sent (include sea freight and insurance) to buyers without charges;
4.Easy torn prts are excluded in the warranty, like plugs, condenser, fuse, battery, seal;
5.Problems caused by customer's incorrect man-made operation will be covered by the user;
6.Part use for overhual and ordinary maintanence will be offered by us in factory price;
7.Skillful engineers of us are available dispatched to customers place for training and service.
