Main Product: diesel engine, diesel generator, alternator and spare parts;
Diesel Engine Usage: Widely used for generator set, boat, wheel loader, truck, water pump, sand pump,
fire pump, construction machine, etc;
Diesel Engine Power Range: from 20kw up to 700kw;
Diesel Generator Power Range: from 30kw up to 700kw.
Low Price 3 Phase Turbine Generator For Sale Technical Parameters
Genset Model (LD Brand) |
LD150GF | LD160GF | |
| Rated Power/Speed kw/r/min | 150/1500 | 160/1500 | |
| LD Diese Engine | Engine Model | LD6LA245L | LD6LA265L |
| Rated Power/Speed kw/r/min | 165/1500 | 176/1500 | |
| Type | Vertical,inline, water-cooled, four stroke | ||
| Intake Way | Turbocharged & Inter-cooled |
||
| Number of cylinders×bore×stroke (mm) | 6-108×140 | ||
| Total displacement(L) | 7.7 | ||
| Min fuel consumption (g/kw.h) | ≤195 | ||
| Starting type | Electric | ||
| Speed governor model | Electric | ||
| Oil capacity(L) | 18-20 | ||
| Low noise limit dB (A) | ≤102 | ||
| Wattek Alternator (Stamford Technology) | Alternator model | 274G | 274H |
| Rated voltage (V) | 400/230 or 380/220 | ||
| Current( A) | 270 | 288 | |
| Freq( Hz) | 50 or 60 |
||
| Regulator approach | AVR | ||
| Power factor (CosØ) | 0.8 Lagging | ||
| Phase | 3Phase 4Wire | ||
| Insulation Class | F / H | ||
| Protection Class | IP22 / IP23 | ||
| Genset Packing | Net weight (kg) | 1800 | 2200 |
| Genset Dimention(LxWxH)mm | 3300x1200x1550 | ||
Low Price 3 Phase Turbine Generator For Sale Warranty Service
1.Warranty iterms will be issued by our own factory, which is simple and quick;
2.Warranty period will be 12 monthes or 1500 working hours from commissioning date;
3.Parts replacement under warranty will be sent (include sea freight and insurance) to buyers without charges;
4.Easy torn prts are excluded in the warranty, like plugs, condenser, fuse, battery, seal;
5.Problems caused by customer's incorrect man-made operation will be covered by the user;
6.Part use for overhual and ordinary maintanence will be offered by us in factory price;
7.Skillful engineers of us are available dispatched to customers place for training and service.
Other Generator Type For Choice
|
|
|
|
| 250~360kw | 80~120kw | 20~50kw | 400~468kw |
|
Ms.Miranda Wang (export/sales manager) Tel: +86 18276782715 Fax: +86 (0)772 2875155 Email: longdao04(at) Skype: LDmirandawang QQ:961156293 |
