Main Product: diesel engine, diesel generator, alternator and spare parts;
Diesel Engine Usage: Widely used for generator set, boat, wheel loader, truck, water pump, sand
pump, fire pump, construction machine, etc;
Diesel Engine Power Range: from 20kw up to 700kw;
Diesel Generator Power Range: from 30kw up to 700kw.
Fishing Boat New Power Marine Diesel Engine Technical Parameters
| Model | LD4F45C | LD4F50C | LD4F55ZC | LD4F60ZC |
| Type | Vertical, in-line, water-cooled, 4-stroke | |||
| Intake Way | Natural aspiration | Turbocharged | ||
| No Cylinders, Bore x Stroke(mm) | 4-100×117 | |||
| Displacement(L) | 3.7 | |||
| Compression ratio | 17:01 | |||
| Rated power/speed(kW/r/min) | 32/1500 | 36/1800 | 40/1500 | 44/1800 |
|
One hour rated power/speed (kW/r/min) |
35/1548 | 40/1858 | 44/1548 | 48/1858 |
| Min fuel consumption g/(kW·h) | ≤225 | ≤215 | ||
| Oil Consumption g/(kW·h) | ≤1.0 | |||
| Starting Type | Electric | |||
|
Crankshaft rotation direction (Face to power output end) |
Anti-Clockwise | |||
| Coupling Size | 3#11.5’’ | |||
| Dimmension (mm) | 986x730x1254 | |||
| Net Weight (kg) | 360 | |||
| Certificate | ISO9001:2008, ZY, CE | |||
Fishing Boat New Power Marine Diesel Engine Features
1. Developed by digesting and absorping the advanced technology from Germany;
2. High intensity crankshaft, cylinder block and cylinder head, all are made of alloy cast iron,with smaller size,
lighter of weight, less vibration, lower nose and higher reliability, the overhaul period is over 12,000 hours;
3. P type high pressure fuel pump and P type injection nozzle, contributing to lower fuel consumption;
4. Special sealing technology for piston ring; lowering ail consumption by over 20% less than similar products
with same power in China;
5. Equipped with electronic speed governing fuel pump, ensuring stable operation.
Except for the above characteristics, all of our marine diesel engines (also land used engines) are vertical,
inline,water cooled, 4 strokes; and equip with trubocharger, water pump, radiator, inter cooler, said these
engines are water cooled turbocharged engines. Whth these superior components, our HD engines is very
effective and function well. The 4F marine engine is 4 cylinder, 4 stroke, water cooled, some of intake way
are natural, some are trubocharged; but nomatter how, they are designed by our genius engineers with good
qualitly.
Fishing Boat New Power Marine Diesel Engine Warranty Service
1.Warranty iterms will be issued by our own factory, which is simple and quick;
2.Warranty period will be 12 monthes or 1500 working hours from commissioning date;
3.Parts replacement under warranty will be sent (include sea freight and insurance) to buyers without charges;
4.Easy torn prts are excluded in the warranty, like plugs, condenser, fuse, battery, seal;
5.Problems caused by customer's incorrect man-made operation will be covered by the user;
6.Part use for overhual and ordinary maintanence will be offered by us in factory price;
7.Skillful engineers of us are available dispatched to customers place for training and service.
Other Type Marine Engine For Choose
|
|
|
|
| 6B 60~120kw | 4BTA 45~65kw | 6BT 80~110kw | 6M 190~300kw |
|
Contacter : Fan Li (Vera) |
