Help CenterLD60GF 75kva 50hz Generator With Super Silent Canopy
Related Products
-
Low Fuel Consumption 60kw 50hz Soundproof Diesel GeneratorUS$ 6,800 - 6,900MOQ: 1 Set -
Stanmford Alrternator Open Style Diesel Genset PriceUS$ 6,800 - 6,900MOQ: 1 Set
-
China Power 3phase 4wire 75kva Generator Cheap PriceUS$ 5,800 - 5,900MOQ: 1 Set
-
2014 Brand New 60kw/75kva Diesel Gen-set for SaleUS$ 5,800 - 5,900MOQ: 1 Set
-
LD80GF CE Certificate Diesel Generator Set 80kwUS$ 6,000 - 6,100MOQ: 1 Set
Main Product: diesel engine, diesel generator, alternator and spare parts;
Diesel Engine Usage: Widely used for generator set, boat, wheel loader, truck, water pump, sand pump,
fire pump, construction machine, etc;
Diesel Engine Power Range: from 20kw up to 700kw;
Diesel Generator Power Range: from 30kw up to 700kw.
| Genset Model (LD Brand) | LD60GF | |
| Rated Power/Speed (kw/r/min) | 60/1500 | |
| LD Diesel Engine |
Engine Model | LD6BT5.9-G1 |
| Rated Power/Speed kw/r/min | 60/1500 | |
| Type | Vertical,inline,water-cooled,four stroke | |
| Intake Way | Turbocharged | |
| Number of cylinders×bore×stroke(mm) | 6-102×120 | |
| Total dispalcement(L) | 5.9 | |
| Min fuel consumption (g/kw.h) | ≤200 | |
| Starting type | Mechnical | |
| Speed governor model | Electric | |
| Oil capacity(L) | 14~16 | |
| Low noise limit dB(A) | 98 | |
| Wattek Alternator (Stanford technology) |
Alternator nodel | 224F |
| Rated voltage(V) | 400/230 or 380/220 | |
| Current(A) | 108 | |
| Freq(Hz) | 50 or 60 | |
| Regulator approach | AVR | |
| Power factor(CosØ) | 0.8 Lagging | |
| Phase | 3Phase 4Wire | |
| Insulation Class | F/H | |
| Protection Class | IP22/IP23 | |
| Genset Packing |
Net weight(kg) | 800 |
| Genset dimension L*W*H(mm) | 3000×1150×14 | |
|
Gen-set Model |
3-PHASE, 4-WIRE | Model | |||
| Prime Power | Engine | Alternator | Controller | ||
| kw | kva | LD Brand | WATTEK | SMARTGEN | |
| LD22GF | 22 | 27.5 | LD4BT3.9-G1 | 184H | 6120 |
| LD40GF | 40 | 50 | LD4BTA3.9-G1 | 224D | 6120 |
| LD50GF | 50 | 62.5 | LD4BTAA3.9-G2 | 224E | 6120 |
| LD60GF | 60 | 75 | LD6BT5.9-G1 | 224F | 6120 |
| LD80GF | 80 | 100 | LD6BT5.9-G1 | 274C | 6120 |
| LD100GF | 100 | 125 | LD6BT5.9-G1 | 274D | 6120 |
| LD112GF | 112 | 140 | LD6BTAA5.9-G1 | 274E | 6120 |
| LD128GF | 128 | 160 | LD6CT8.3-G1 | 274F | 6120 |
| LD150GF | 150 | 188 | LD6CTA8.3-G2 | 274G | 6120 |
| LD160GF | 160 | 200 | LD6CTAA8.3-G2 | 274H | 6120 |
| LD200GF | 200 | 250 | LD6LTAA8.9-G2 | 274K | 6120 |
1.Warranty interms will be issued by our factory,which is simple and quick;
2.Warranty period will be 12 monthes or 1500 working hours from commissioning date;
3.Parts replacement under warranty will be sent(include sea freight and insurance)to buyers witthout charges;
4.Easy torn parts are excluded in the warrenty,like plugs,condenser,fuse,battery,seal;
5.Problems cased by customer's incorrect man-made operation will be covered by the user;
6.Part use for overhaul and ordinary maintance will be offered by us in factory price;
7.Skillful engineers of us are available dispatched top cuatomers palce for training and service.
|
Ms.Miranda Wang (export/sales manager) Tel: +86 18276782715 Fax: +86 (0)772 2875155 Email: longdao04(at) Skype: LDmirandawang QQ:961156293 |
