Paperless temperature data logger
Technical Parameter of Paperless temperature data logger:
Screen: 5.6 inch TFT true color LCD screen or blue LCD, 320*240dot matrix, LED backlight.
Accuracy: Real time display: ±0.2% F.S.;
Curve display: ±0.5% F.S.;
Recall precision: ±0.2% F.S.;
Input specs: Fully isolated universal input, 1 ~ 16 channel signal input, the full isolation between channels, the isolation voltage greater than 1000V;
Isolation impedance: 20MΩ @ 1000V;
Recording capacity: 64/128/192/248MB(FLASH capacity can optional);
Voltage input:0-5V,1-5V,0-20mV,0-100mV ( >1MΩ);
Current input:0-10mA,4-20mA(Impedance 250Ω);
Thermal resistance: PT100,Cu50(Requires three wire resistance balance, lead wire resistance<10Ω);
Thermocouple: S,B,K,T,E,J,F2;
Isolated distribution: Transmitter distribution+24VDC,Maximum 16 way isolated power distribution,Distribution≤30mA/channel;
Analog output:4-20mA;overload 750Ω(max);
Relay alarm output:12 channel relay contact output,contact capacity 3A@220VAC/1A@30VDC;
Communication, print:Communication interface----RS232Cor RS485,Baud rate----(1200,2400,9600,19200),Print interface----RS232C directly connected micro printer;
Recording interval:1 second to 240 seconds,total 11 grades:1/2/4/8/12/24/36/60/120/180/240s can optional;
