Specifications

pneumatic air booster

Description

QSY-103 pneumatic booster is one of the attachment accessories of  jet technology.As pressure and flow amplification purposes, which takes the pressure (0.2 ± 0.02Mpa) signal, the output of the high-pressure (0.4-0.6Mpa), to promote the pneumatic actuator institutions, to achieve the power amplifier, agile purposes.

Technical parameters

1 the signal pressure: 0.20 ± 0.02Mpa (clean air)

2 air pressure: 0.4 ~ 0.6Mpa (clean air)

3 the working environment: temperature - 10 to +60 degrees, relative humidity <35%, the air should not contain non-ferrous metal plating and its corrosive effect media.

4 the maximum air consumption: about 15 l / min.

5 Dimensions: 255 x 195 x 120mm

6 booster weight: about 6.5kg.
