RTD pt100Temperature Transmitter
Parameter:
Working standard: two-wire 4 ~ 20mA
RTD input signal output is (1) two-wire system (2) three-wire system
Accuracy rating: 0.2% FS, 0.5% FS.
Operating voltage: DC24V ± 1V.
Range: Thermal resistance Pt100 (special scale user can specify) 0 ℃ ~ 50 ℃; 0 ℃ ~ 100 ℃; 0 ℃ ~ 150 ℃; 0 ℃ ~ 200 ℃; 0 ℃ ~ 300 ℃; 0 ℃ ~ 600 ℃.
working environment:
Temperature: 0 ℃ ~ 50 ℃, Humidity: 45 ~ 85% RH.
Load capacity: ≤400Ω.
Dimensions: 45mm × 41mm
Input signal: thermal resistance Pt100, Cu50, Cu100,
Measuring distance 10 ℃, any of the above temperature range
Output signal: Current: (4 ~ 20) mA DC
Load Resistance: ≤500Ω
The basic error: ± 0.5%
Temperature drift: ± 0.1% / 10 ℃
Transmission mode: two-wire transmission
Operating temperature:
Temperature (-10 ~ 75) ℃ humidity ≤90%)
Power: 24V DC ± 2V (or with electrical, barrier power supply)
Power consumption: ≤0.5W
About Us:
Xi'an Yunyi Instrument Co., Ltd. is a professional manufacturer that engaged in the fields of pressure measurement instrument, the chief engineer Mr Tian has more than 30 years on this area, he is one of the engineers who introduced the Rosemount technology. We specializing in developing high precision pressure transmitter and pressure gauges. And we also develop temperature transmitter, level transmitter, densitometer etc. They are widely used in chemical, petroleum, paper, electricity, city gas, environmental protection, water treatment and other fields.
