Head Mounted Temperature Transducer
- beijing shanghai shenzhen tianjin
- T/T L/C D/P D/A Money Gram Credit Card PayPal
You May Like
Product Details
| Place of Origin | Shaanxi, China | Brand Name | Yunyi | |
| Model Number | YDK322-F | Usage | Industrial | |
| Theory | Temperature Transmitter | Accuracy | ±0.25% | |
| Temperature Range | - 200 ~ 1800 ℃ |
head mounted temperature transducer
Corrugated cardboard boxes outer and foam paper inner packing size: 4x5x14cm
Product Description
Head mounted temperature transducer
Description of head mounted temperature transducer :
Charateristics of head mounted temperature transducer :
1. Can two wire transfer. Two signal converter power supply wire and the output signal
2. Constant current output signals or constant pressure, strong anti-jamming capability, remote transmission performance is good.
3. Signal converter with epoxy resin encapsulation into modules, with the advantages of shock resistance, corrosion resistance, moisture proof, can be used in conditions of poor areas.
4. Thermocouple millivolt signal through the signal converter directly into 4 ~ 20 ma output current, using ordinary cable transmission signal, can save expensive compensation conductor.
5. A live show of temperature transmitter output 4 ~ 20 ma current signal, and can read the measured temperature at the scene of the temperature measurement, was a great convenience to the operating personnel.
6. High precision, good anti-jamming, long term stability, free maintenance, remote transmission (as far as 1000 meters).
1 .Range: - 200 ~ 1800 ℃
2. Conventional precision: plus or minus 0.25%
3. Power supply voltage: 13 ~ 30 v DC
4. load resistance: 0 ~ 850Ω
5. Output signal: 4 ~ 20 ma
6. Basic error: plus or minus 0.2%, plus or minus 0.5%
Company Profile
Xian Yunyi Instrument Co., Ltd. is a professional manufacturer that engaged in the fields of pressure measurement instrument, the chief engineer, Mr Tian has more than 30 years experience on this area, and he is one of the engineers who introduced the Rosemount technology. We are specialized in developing pressure transmitter, etc. They are widely used in chemical, petroleum, paper, electricity, city gas, environmental protection, water treatment and other fields.
Contact Us
- Xi'an Yunyi Instrument Co., Ltd.
- Contact nameSunny Zhang Chat Now
- Phone86-29-88812007
- AddressNo. 309, Building A, Ronghe Bldg., No. 218, Huancheng West Road, Shaanxi, China
