Dry body temperature calibrator
Description:
PD-2400 dry asanas temperature calibrator, through the design of its small portable size sophisticated; simple operation; facilitate field work site and place no AC power supply 24V DC power supply can be used in the design, particularly applicable to all kinds of temperature sensors, direct-reading thermometer gauge in place, and all kinds of temperature switch maintenance, inspection and field verification and comparison of short branched temperature probe calibration.
Use PD-2400 dry asanas temperature calibrator can simulate an actual temperature in situ source, used to discover or suspect that you provide a true and accurate temperature measurement system verification program. For require periodic calibration, inspection measurement system may be exempted from the component disassembly trouble and retrieve laboratory validation errors may occur.
Parameter:
| Temperature range | above ambient temperature up to 10 ℃ to 400 ℃ |
| Working medium | air |
| Tank dimensions | Diameter 25.4 / 18.6mm; deep 165mm |
| Work areas | diameter 16mm; deep 165mm |
| Cooling / heating mode | 24VDC DC heating / cooling fan is directly trough |
| Temperature control | digital PID temperature control |
| Display resolution | 0.01 ℃ |
| Temperature stability | better than ± 0.02 ℃ |
| Display accuracy | digital PID temperature control |
| Display resolution | 0.01 ℃ |
| Temperature stability | better than ± 0.02 ℃ |
| Display accuracy | ± 0.2 ℃ (after calibration) |
| Warm-up time | about 20 minutes (50 ℃ rose to 400 ℃) |
| Cooling time | about 25 minutes (400 ℃ down to 50 ℃) |
| Operating voltage | 220V ± 10% single phase AC mains; 24V / 7AH (Ah) DC battery power |
