Home > Products > Temperature products > Combination Pressure Temperature Transmitter
Combination Pressure Temperature Transmitter
- 1000 Piece / Pieces per Month
- Tianjin
- T/T L/C D/P D/A Credit Card PayPal
Product Details
Place of Origin: | Shaanxi, China | Brand Name: | Yunyi | Model Number: | PT3 |
Usage: | Indoor | Theory: | Temperature Transmitter | Accuracy: | ±0.5℃ |
Temperature Range: | -50-300℃ |
Packaging Details
Combination Pressure Temperature Transmitter
one piece package:23*14*11cm
weight:0.75KG
Product Description
Combination Pressure Temperature Transmitter
Description :
Integration of temperature and pressure sensors, transmitters integrated temperature and pressure sensors, transmitters PTJ406 integrated temperature and pressure sensors, transmitters
Imported movement, thermocouple types: J, K, E-type or PT100 beat resistance, temperature and pressure integrated structure, which can measure the same point of the medium pressure and temperature for the simultaneous measurement of the pressure of the media to be measured the temperature of the occasion.
.
Specification :
Range | 0-800 KPa-20Mpa etc |
-50---+200℃/300℃ | |
Output | mv,4-20mA,0-10mA,0-5V,0-10V ANY |
Accuracy | 0.2 %F·S |
Zero drift | ±0.2 %F·S/10℃ |
Power | 9 VDC,12 VDC,24 VDC |
Working temperature | -20 ~ +80 ℃(CUSTOM) |
Output | FOUR WIRE |
Over pressure | 150 %F·S |
Medium | Compatible with 316 stainless steel gas, liquid |
Material | SS |
Thread | M20×1.5(G1/2,G1/4 etc) |
About Us:
Xi'an Yunyi Instrument Co., Ltd. is a professional manufacturer that engaged in the fields of pressure measurement instrument, the chief engineer Mr Tian has more than 30 years on this area, he is one of the engineers who introduced the Rosemount technology. We specializing in developing high precision pressure transmitter and pressure gauges. And we also develop temperature transmitter, level transmitter, densitometer etc. They are widely used in chemical, petroleum, paper, electricity, city gas, environmental protection, water treatment and other fields.
If you need this Combination Pressure Temperature Transmitter , please contact
Katherina Wang skype:wangxiaoyuncalar
Or visit website for more details
Company Profile
Xian Yunyi Instrument Co., Ltd. is a professional manufacturer that engaged in the fields of pressure measurement instrument, the chief engineer, Mr Tian has more than 30 years experience on this area, and he is one of the engineers who introduced the Rosemount technology.
We are specialized in developing pressure transmitter, etc. They are widely used in chemical, petroleum, paper, electricity, city gas, environmental protection, water treatment and other fields.
