KY Piston Type Pressure Gauge

KY Piston Type Pressure Gauge thumbnail-1
KY Piston Type Pressure Gauge photo-1
US$ 1,000 - 2,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Place of Origin:
Shaanxi, China
Brand Name:
Yunyi
Model Number:
KY series
Contact Supplier Request Quote Chat Now
Xi'an Yunyi Instrument Co., Ltd.
Gold Verified Supplier
5Yrs
Payment & Shipping
Payment Methods:
Port of Shipment:
beijing shanghai tianijin shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shaanxi, China
Brand Name Yunyi
Model Number KY series

KY piston type pressure gauge

Description of KY piston type pressure gauge :

KY series wide-range piston type pressure gauge is my institute according to the country the latest verification regulations and requirements of piston manometer new research and development design and manufacturing. Due to the key components of the piston pressure gauge with high hardness and low temperature coefficient of linear expansion of tungsten carbide material, so as to improve the wear resistance of the piston, therefore under pressure after deformation (negligible), minimum performance is very stable. The working medium of piston adopted sebacate diisooctyl, so that the pressure gauge has a very high sensitivity.



Performance feature of KY piston type pressure gauge :

1. The pistons and piston cylinder adopt high strength, high hardness, and low temperature linear expansion coefficient of the carbide tungsten carbide materials carefully made, grinding, wide working temperature stable performance of 20 + / - 5 ℃.
2. Load low center of gravity, weight through the hanging basket directly on the piston, piston smooth operation, little pressure fluctuation, the accurate value.
3. More than 25 mpa pressure transfer medium using viscosity small sebacate diisooctyl, thus ensuring pressure gauge with high sensitivity.
4. The pressure gauge used farmar all adopt the non-magnetic stainless steel making
5. The pistons work position with the displacement sensor monitoring, piston stroke up and down to + / - 1.5 mm, instrument display has the advantages of quick, eye-catching, accurate.
6. Wide range, the lower limit of 1 mpa, the fundamental error of plus or minus 0.02% or + / - 0.05%, a KY100 type pressure gauge, is worth at present domestic measurement limit 6, 60, 100 mpa three pressure gauge is used.
7. Pressure regulating light energy, even in the 100 mpa pressure can also be at ease.

The main technical parameters: wide-range piston manometer specification table



KY-2.5

-0.1-0.25Mpa

-0.1-0.4Mpa

-0.1-0.6Mpa

KY-0.6

0.04-0.6Mpa

KY-6

0.1-6Mpa

KY-25

0.5-25Mpa

KY-60

1-60Mpa

KY-100

1-100 Mpa

Ky-250

5-250Mpa




KY piston type pressure gaugeKY piston type pressure gauge
