Specifications
I-shaped diaphragm pressure gauge1 professional manufacturer
2 quick shipment
I-shaped diaphragm pressure gauge
The specification of I-shaped diaphragm pressure gauge :
YTP100-MG -shaped diaphragm pressure gauge Product Remarks
table diameter : 60MM 100MM 150MM
accuracy : ± 1.5%, ± 2.5%
material : 0Cr17Ni12M02 (316), Hastelloy (H276c), Monel (Cu30Ni70), Ri alloy (Ta), fluorinated material (F4)
flange material : 0Cr17Ni12M02 (316), stainless steel lined plastic (316 + F4)
gasket material : nitrile rubber , fluoro rubber, silicone rubber and fluorine plastics .
The form of the diaphragm and the diaphragm gauge pressure range : MF: open form of raised face (≤ 25MPA) / MG: I-shaped (≤ 6MPA) / ML: threaded (≤ 60MPA) / MZ: Bolt (≤ 1 ~ 25MPA) / homogenizer machine (10 ~ 60MPA) / MC: clip-type (01 ~ 2.5MPA
MN: Nut (0.1 ~ 2.5MPA) / MF: Clamp flange (≤ 6MPA) / GL: corner flange (≤ 6MPA)
Linkers form and temperature : SR: Radiator ( measured medium temperature <200 °C) / YL: rigid pipe connections ( measured medium temperature <200 °C) / RL1/2/4: hose connection / GL: angled connector ( measured medium temperature <100 °C) / ZN: direct , dampers / Note: Incomplete direct connection type
Diaphragm pressure gauge diaphragm liquid options:
Ministry of sealing liquid pressure temperature range gravity g / cm volume expansion coefficient 1 / °C Uses
High -stick silicone diaphragm pressure gauge degrees -10 ~ 200 °C 1.07 0.95-10-3 high temperature
Low-viscosity silicone diaphragm pressure gauge -30 ~ 100 °C 0.94 1.08-10-3 general use
glycerol solution -5 ~ 100 °C 1.27 0.61-10-3 food
gauge vegetable -5 ~ 100 °C 0.93 1.03-10-3 food
fluorine oil -30 ~ 150 °C 1.93 0.75-10-3 hydrogen, oxygen
About Us:
Xi'an Yunyi Instrument Co., Ltd. is a professional manufacturer that engaged in the fields of pressure measurement instrument, the chief engineer Mr Tian has more than 30 years on this area, he is one of the engineers who introduced the Rosemount technology. We specializing in developing high precision pressure transmitter and pressure gauges. And we also develop temperature transmitter, level transmitter, densitometer etc. They are widely used in chemical, petroleum, paper, electricity, city gas, environmental protection, water treatment and other fields.
If you need this diaphragm pressure gauge , please visit the website
