Fertilizer bucket elevator bucket elevator
1. Description of the fertilizer bucket elevator bucket elevator
The bucket elevator is applicable for conveying the power, grain and block materials, such
as coal, cement, block, sand, clay and ore. The bucket elevator is allowed to convey materials
with high temperature when armed with special circle chain structure.
Bucket elevator is allowed to transport the materials with high temperature (the materials’
temperature does not exceed 250 °C). General transport height is up to 40 meters.
2. Features of the fertilizer bucket elevator bucket elevator
1..Low driving power
2.Wide lifting range
3.Good running reliability
4.Wide application
3. Working principle of the fertilizer bucket elevator bucket elevator
The materials are scooped up by the hopper and brought to the top along with the conveyor
belt or conveyor chain, and then the materials will roll down after bypassing the top wheel, and the
bucket elevator will pour the materials to the receiving chute. The driving belt of bucket elevator
with driving belt often uses rubber belt which is installed on the upper or lower transmission drum
and the upper or lower redirection transmission drum.
4. The technical parameters of the bucket elevator
| Specification | Max. lifting height (m) | Capacity(t/h) | Pitch of buckets (mm) | Motor power (kw) |
| 160 type | 28 | 3-8 | 500 | 3-7.5 |
| 200 type | 31.5 | 6-15 | 500 | 3-7.5 |
| 250 type | 30.16 | 10-25 | 500 | 4-11 |
| 300 type | 30.16 | 25-35 | 500 | 5.5-15 |
| 350 type | 31 | 19-40 | 600 | 7.5-18.5 |
| 400 type | 32 | 35-50 | 600 | 7.5-22 |
| 450 type | 32.7 | 42-60 | 600 | 7.5-22 |
Pre-sales services
1.Guide customers to choose products which are best suitable for them.
2.Design and manufacture tailor-made products according to the specific needs of customers.
Sales services
1.Strict inspection before the delivery of equipment.
2.Arrange the delivering of goods in accordance with contract.
After sales services
1.Designate special after-sales service personnel to instruct customers to install equipment.
2.For the problems, our company guarantee to provide resolutions within 24 hours.
Henan Songshan Heavy Industry Co., Ltd., a state designated manufacturer by National Construction Department,has a history of over 30 years in machine manufacturing.
We mainly specialize in manufacturing beneficiating , crushing and milling machines,such as Jaw Crushers, Impact Crushers, Double Roll Crushers, Sand Making Machines,Raymond Mills, Superfine Mills, Ball Mills, Flotation Separators, Magnetic Separators,Shaking Tables, and Dryers.
Our products have received the ministerial and provincial honors. Due to the high quality and
perfect after sales service, our products have won trust and good comments from our customers
and taken the lead in the machinery fields.
Customer visiting
Please don’t hesitate to inform us:
1.What's kind of your raw material?
2.What's your raw stone size?
3.What's the capacity ? (T/H)
4.What's the final stone size request?
