Steam Handheld Ultrasonic Flow Meter

Name: Steam Handheld Ultrasonic Flow Meter
Brand: Yunyi
Availability: InStock

FOB Price

US$ 100 - 500 / Unit

1 Unit(Min. Order)

Port Dalian
Payment TermsT/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Shaanxi, China		Brand Name	Yunyi
Model Number	TDS-100H

Packaging Details

ultrasonic flow meter
Corrugated cardboard boxes outer and foam paper inner

Product Description

Steam handheld ultrasonic flow meter

TDS-100H ultrasonic flow meter for sale with the capability of a full size flow meter. It is carefully designed for portability and ease of use.

Specifications of ultrasonic flow meter :

* Better than 1% accuracy.

* 0.2% of repeatability.

* Positive / negative / net flow totaliser

* 4 line LCD display.

* Operate with clamp-on transducers.

* RS-232/OCT output

* Ni-MH Battery life for up to 12 hours continuous operation.

Features of ultrasonic flow meter :

Repeatability	Better than 0.2%
Accuracy	±1% of reading at rates>0.2 mps
Response Time	0-999 seconds, user-configurable
Velocity	±32 m/s
Totalizer	7-digit totals for net, positive and negative flow respectively
Liquid Types	Virtually all liquids
Security	Setup values Modification Lockout. Access code needs unlocking
Display	4x8 Chinese characters or 4x16 English letters, display instant flow, velocity, total flow, signal status
Signal output	Non-isolation RS232(FUJI extension protocol), one channel isolation OCT output
Transducers	Clamp on type transducers
Transducer Cord Length	Standard 2x10 meters, optional 2x 500 meters
Power Supply	3 AAA Ni-H built-in batteries. When fully recharged it will last over 12 hours of operation. 100V-240VAC for the charger
Data Logger	Built-in data logger can store over 2000 lines of data Housing Material ABS
Case Size	100x66x20mm
Handset Weight	514g (1.2 lbs) with batteries
