High Purity Graphite Sheet For Sale
1.General Specification: thickness 0.05-0.15mm/ 0.2-1.5mm/ 2mm
width 1000mm/610mm/500mm
length 50-200m
2.Main Usage: To make composite sheet, cylinder gasket, packing ,gasket, solid sealing parts such as level gages, crystallizers and flanges.
3.Main Technical Data:
Item |
Class A |
Class B |
Class C |
Tolerance of density(0.7-1.1g/cc) |
±0.05 |
±0.10 |
±0.16 |
Tolerance of thickness(mm) |
±0.02 |
±0.03 |
±0.04 |
Carbon content (%) |
99.8 |
99.5 |
99 |
Tensile strength (Mpa) |
5.0 |
4.5 |
4 |
Compressive strength (Mpa) |
168 |
168 |
168 |
Compressive rate (%) |
≥45 |
≥43 |
≥41 |
Elastic rate (%) |
≥13 |
≥12 |
≥11 |
Sulphur content (ppm) |
≤500 |
≤800 |
≤1200 |
Fluorine content(ppm) |
≤30 |
≤40 |
≤50 |
1. Wooden Case Packing Method
2. As your special requirements
1. What kind of graphite sheet could you provide?
Thickness from 0.05-2mm, Length from 50-200m, width 500mm/1000mm. We could produce it as your requirements.
2. Could you offer a competitive price for graphite sheet?
We located in Qingdao, which is rich in the raw material of expandable graphite sheet- expandable graphite powder, so we could control our raw material and provide a reasonable price for you.
3. Payment method?
We mostly use 30% T/T, the rest against the copy of B/L, OR L/C.
4. Could I test the sample?
Yes, we're very please to do so. Generally, we provide A4-paper size graphite sheet for our clients to test. We could provide the free sample, and please kindly pay the shipping cost to your address.
