Low cost differential pressure manometer digital

pressure manometer digital
Corrugated cardboard boxes outer and foam paper inner

Specifications

pressure manometer digital
made in china
manufacturer offer
high quality and low price

Low cost differential pressure manometer digital





Working Principle of pressure manometer digital :

yokogawa pressure transmitter  is used to measure level,density and pressure of liquid, gas or steam, and then convert pressure

signal into 4~20mA/0~20MA/0~5VDC/1~5V/0~10VDC signals.



Application Field of pressure manometer digital :

1. Petroleum / Petrochemical / Chemical

2. The electricity / City gas

3. Pulp and paper

4. Iron and steel / Nonferrous metal / Ceramic

5, The mechanical / Shipbuilding industry



Technical Parameters of pressure manometer digital :

Measured Medium: Gas, liquid(no corrosion of stainless steel)

Measured Range:  -0.1~0~0.001~100MPa(within any range)

Pressure Type: Negative pressure, absolute pressure, standard pressure,

sealing pressure (not required default gauge)

Accuracy:   0.1,  0.25,   0.5,(default 0.5)

Connection Size: M20*1.5(default)  Others optional: G1/2, G1/4, G1/8, G3/8, G3/4, 1/4NPT, 1/2NPT, 1/8NPT.

Long Stability: ±0.1% F.S/Year

Temperature Drift: ±0.01%FS/℃

Power Supply: 18-36VDC (default 24V)

Output: 4~20mA (default)  or  0-5VDC or 0-10VDC or 1-5VDC or 0~20mA

Medium Temp: -40-85℃

Environment Temp: -40-85℃

Over Pressure: 150%

Seal Grade: IP65

Sampling frequency: ≤2ms

Probe Material: Stainless Steel

Over Load: (Current type)250~1425Ω (Voltage type)≥2KΩ
