300KN MTS Hydraulic Tensile Strength Testing Machine Price
- 1000 Set / Sets per Month
- Qingdao Port
- T/T Credit Card PayPal
Product Details
Place of Origin: | Shanghai, China | Brand Name: | MTS | Model Number: | SHT4305 |
Power: | Electronic | Usage: | Tensile Testing Machine |
Product Description
MTS SHT4305-W tensile strength test machine
Description of equipment:
300 kNmicrocomputer control electro-hydraulic servo universal testing machine, to stretch space between upper and lower beam, the beam and try for the compression space between. Tension and compression experiment transformation is very convenient; The digital high response measurement system based on DSP, load, strain measurement not step all the way, test force resolution up to 300000 yards. 12 MB/s data transmission using USB communication, high-speed links; Meet the GB/T 228-2002 metal materials tensile test at room temperature and standard requirements, automatically calculate the results of the parameters specified in the relevant standard (configuration corresponding fixture or deformation measurement devices as needed).
Main functions:
Used for all kinds of metal material specimen tensile, compression, bending and shear test, and some special test products.
Main features:
1: to stretch space between upper and lower beam, the beam and try for the compression space between. Tension and compression experiment transformation is very convenient;
2: the structure of worm gear and worm, eliminate the influence of screw clearance on experimental curve and test curve makes more perfect.
3: adopt double flange high accuracy sensors and piston rigid connection, a strength more accurate test, the sample fracture on the ground when the impact force is small, semi-closed structure is used in jaw rigidity is better;
4: oil source USES the mute design, environmental protection, humanization, unique differential pressure servo system, reduce the energy consumption and reduce fever and protect oil;
5: using high-speed DSP platform, and its high integration, powerful control, data processing ability, high reliability, is to use other processors of the testing machine can not reach.
6: using full digital based on neuron adaptive PID algorithm, the three closed loop (force, deformation and displacement) control system, the implementation force, deformation and displacement of full digital closed loop control, can automatically switch between each control loop, and no impact on the when switching between all the way to realize smooth transition.
7: preciseness 24 bit data acquisition system, high resolution, can be extended to 8 way AD collection.
8: USB1.1 communication, the communication rate of 12 MB/s, adopt the mode at full speed, mass transport.
9: unique anti-interference system board USES 4 layer PCB wiring method, strong anti-jamming capability.
10: in addition to the power supply interface, all other interface with a standard USB interface, plug and play interface this interface can realize hot plug, which have the function of plug and play. Interface features can be set up by the software online. Make each interface neat layout reasonable, easy to plug.
Bolt tensile clamp, nut load, bending fixture, shear clamp
Application industry:
Measuring quality inspection; Metallurgical steel; Mechanical manufacturing; Electronic appliances; Car production. Wire and cable; Civil aviation; Colleges and universities; Scientific research test; The commodity inspection arbitration, technical supervision departments; Building materials ceramic; Petrochemical industry; Other industries.
Technical parameters:
SHT4305 microcomputer control electro-hydraulic servo universal testing machine technical parameters | |
specifications | SHT4305 |
The biggest test (kN) | 300 |
Testing machine precision | Level 1 /level 0.5 |
Test force relative error value | Within ±1%/±0.5% |
Test force measurement range | 1%-100%FS( The entire don't step) |
Deformation ( extensometer) measurement range | 1%-100%FS |
Deformation relative error value | Within ±1%/±0.5% |
Deformation of the resolution | Most of the deformation 1/300000 |
The piston movement speed range | 0-200mm/min |
Test force loading rate range | 0.02%—2%FS/s |
The biggest space stretch jaw (mm) | 630 |
The largest compression space (mm) | 550 |
Circular sample holder block clamping range (mm) | φ10-φ20 φ20-φ32 |
Allow extension configuration rebar sample specifications | φ6-φ14 φ16-φ22 |
Plate specimen clamping thickness (mm) | 2-25 |
Platen size (mm) | φ120 |
Piston stroke (mm) | 150 |
Host overall dimensions (length x width x height in mm) | 940×610×2000 |
Oil source dimension (length x width x height in mm) | 1150×600×900 |
Total power (kw) | 5 |
Weight (kg) | About 2000 |
We adopt The standard export of conventional fumigation wooden cases.
Shipping from Qingdao port, is expected to arrive within 30days.
After-sales Service:
If you face any problems in future during testing process, we promise we will give you a reply within 24 hours and solution provide within 3 working days.
We can offer operation video and English operation software.Also we can provide video-conference.
If customers require on-site service, the transport and travel expense shall be borne by customer.
Shandong Banner International Trade Co., LTD. , is your most reliable test helper in material testing industry. Bannerglobal is our brand. The founder and main leaders of our company worked in MTS Systems Corporation more than ten years and provided solutions for various demanding and extremely complex material testing in many fields of China. Our goal is to create the best test experience for customers by providing the best quality products, professional technical support and world-class service to ensure accuracy, repeatability and reliability of test data.
Why choose us?
With advanced technology, superior performance and stable quality and enjoys a good reputation inside and outside the industry, market share in a leading position, universal testing machine product line has been basically covers all the models and the testing of all the possible scope, both from the micro (desktop) universal material testing machine, or in very large electronic universal material testing machine system , we all can provide make you satisfied material testing solutions
In addition,our warranty for 1 year.
If you face any problems in future during testing process, we promise we will give you a reply within 24 hours and solution provide within 3 working days.
We can offer operation video and English operation software.Also we can provide video-conference.
If customers require on-site service, the transport and travel expense shall be borne by customer.
1. How is the quality of the product?
A: Our product has high reliability and easy operation, these test systems use high speed, low vibration motor drive device and integrated, digital closed-loop control device, to achieve force control, displacement or strain control test. We provide the most abundant product lines in the industry, such as electronic universal testing system by screw driven, electro-hydraulic servo fatigue testing system, impact test system, biological tissue engineering test, structural test and collision analog system, etc. Our customers cover almost all markets and industries of the world, including regenerative medicine, aerospace, energy, electric power, heavy industry, electronics and automobile manufacturing.
2.What about your delivery time?
A: Within 1 month.
3. How about the packing for testing equipment?How about if damaged during shipping?
A: We use the standard export of conventional fumigation wooden cases.Please don't worry,it will not damage in transport.
