Sales champion:concrete compression testing machine
- 100 Set / Sets per Month
- QINGDAO
- T/T Credit Card PayPal
Product Details
Place of Origin: | Shanghai, China | Brand Name: | MTS | Model Number: | CBT1000 |
Power: | Electronic | Usage: | Compression Testing Machine |
Product Description
This product is suitable for compressive strength test of bricks, stones, cements and concretes, which can also be used for compressive properties test of other materials. The machine adopts micro flow valve, high-precision pressure sensor, and computer automatic constant loading control, which ensures high control precision and good reliability, it also uses electric screw lift to adjust the test space; the operation is easy and convenient.
CBT1000 Hydraulic Compression testing machine/ Concrete compression test machine Main function:
It is specially used to test the flexural strength of concrete, and it can meet the requirements of the concrete flexural test in the test method of mechanical properties of ordinary concrete, and also meet the requirements of ISO, ASTM and other standards for cement mortar materials testing.
CBT1000 Hydraulic Compression testing machine/ Concrete compression test machine Technical parameters:
Model | CBT1504,CBT1105,CBT1205,CBT1305 | |
Measurement parameters | Maximum test force | 50kN,100kN,200kN,300kN |
Accuracy class | 1 | |
Test force measurement range | Full range 0.2%~100% | |
Column number | 2 | |
Two column net distance | 300mm | |
Test force resolution | Maximum test force 1/300000 | |
Test force measurement accuracy | Value ±1% | |
Control parameter | Force control range | 0.02-5% FS/s |
Relative error of force control | ±1.0% | |
Upper and lower pressure head | 180mm | |
On the span | 150mm/100mm | |
Under the span | 450mm/300mm | |
Branch roll length | 160mm | |
Branch roll diameter | Φ30mm | |
Maximum stroke | 100mm | |
Maximum speed | 50mm/min | |
Other | Motor power | 1.5kW |
Host size | 1230*700*1650 | |
Power Supply | 380V/50HZ | |
Weight | 1100kg |
Meet standards:
GB/T10128-1998 "metal room temperature torsion test method"
Meet standards:
Test method of mechanical properties of ordinary concrete GB/T50081-2002
Application industry:
Measurement and quality control; high school; Research Institute; commodity inspection and arbitration, technical supervision departments; building materials ceramics; other industries.
Original configuration:
1 sets of concrete anti bending device
Scalable configuration:
Protective cover
.
Packaging& Shipping:
Fumigation and by standard export wooden case.
Ship from Qingdao port, is expected to arrive about 30days
Mobile: +8615866073062
Skype: betty_3541
Tel: +86 537 3167400 Fax: +86 537 3165401
Shandong banner international trade Co.,Ltd
Web:
www.bannerglobal.en.china.cn
1. Pre-service
24 Hours online service for your consult.
Help choose right model,and a series of service,person,advise.
2. Middle service
--Give you best offer
--Provide discount for many sets order
--Do customer's request:
--Choose payment term you convienent.
--Promptly production and delivery,inform you in time.
--Can provide invoice value as you like to decrease your tax.
3. After sale service
--1 year warranty service and all life maintenance.
--Technical Egineer are avalible for oversea trainning.
--Free change for some parts
--Remote control technical consult
--Free installation DVD
--Maintenance plan
4,Commitment:
We will sign a letter of commitment while we sign the contract, which will improve your confidence to us.
5,Good Packaging:
Good Packaging: Simulation Animatronic Customer Triceratops are covered with air bubble film before put them into the wooden case, which not only has good shock absorption, impact resistance, heat sealing and also has the advantages of nontoxic, odorless, moisture corrosion, good transparency etc.
