MTS pendulum impact testing machine for plastic
New Exceed series plastic pendulum impact system, has the characteristics of high reliability, stability, is suitable for impact resistance performance test of plastic, nylon, rubber and so on nonmetal materials, can carry on a variety of test and data processing according to GB, ISO, ASTM standards.
New MTS Exceed plastic pendulum impact system expands the testing skills, leading technology advantage and unmatched global support, make MTS solutions for a wide range of R&D test the backbone of the production test applications. By integrated solid host, high resolution electric control system, comprehensive security device, Exceed plastic impact pendulum system (MTS) for the stability of the quality control and the normal operation of the mass production environment, and all kinds of high strength industrial testing with high reliability, high safety testing capability.
characteristics
1.Strong main frame, grey iron casting, absorb shock vibration effectively
2. Reliable disc brakes, pendulum brake quickly, improve test efficiency, provide security;
3. Quick replacement of pendulum without other tools
4. In line with the ergonomics of the operation panel, large size display, tilt Angle design, comfortable operation, easy to read.
5. High resolution without shaft encoder, reduce the energy loss, accurate measurement pendulum impact Angle;
6. Effective safety protection device
7. Printer, PC via RS232 connection;
8. Comply with the CE standard;
Technical parameters
Specification |
E21.550 |
E21.251 |
|
Maximum impact energy
|
5.5J
|
25J
|
|
Impact speed
|
2.9-3.46 m/s
|
2.9-3.8 m/s
|
|
Dimension of the main tester (W x H x D)
|
1055 x 1060 x 520 mm
|
1228 x 1220 x 520 mm
|
|
Weight (accessories excluded)
|
210 kg
|
250 kg
|
|
Impact test results, digital display
|
Impact energy (J) Impact strength (kJ/m²)
|
Impact energy (J) Impact strength (kJ/m²)
|
|
Unit
|
SI
|
SI
|
Functions |
Friction loss correction Period of oscillation Automatic calculation of the pendulum length Linkable printer Linkable PC Brake
|
Friction loss correction Period of oscillation Automatic calculation of the pendulum length Linkable printer Linkable PC Brake
|
safety protection |
Basic safety protection device
|
Basic safety protection device
|
|
Interface
|
RS 232
|
RS 232
|
|
Angle resolution
|
0.045°
|
0.045°
|
|
Power supply
|
100~240 V AC
|
100~240 V AC
|
If you face any problems in future during testing process, we promise we will give you a reply within 24 hours and solution provide within 3 working days.
We can offer operation video and English operation software.Also we can provide video-conference.
If customers require on-site service, the transport and travel expense shall be borne by customer.
Shandong Banner International Trade Co., LTD., is your most reliable test helper in material testing industry. Bannerglobal is our brand. The founder and main leaders of our company worked in MTS Systems Corporation more than ten years and provided solutions for various demanding and extremely complex material testing in many fields of China. Our goal is to create the best test experience for customers by providing the best quality products, professional technical support and world-class service to ensure accuracy, repeatability and reliability of test data.
Our product catalog:
Electronic universal testing machine
Hydraulic universal testing machine
Electronic torsion test machine
Tensile testing machine
Pressure testing machine
Pendulum impact testing machine
Packed by standard export fumigated wooden cases.
Ship from Qingdao port, is expected to arrive about 30days
Q1: I want to buy your products, how can I pay?
A :You can pay via T/T , T/C, Western Union,MoneyGram or other payment terms we reach agreement.
Q2: How can you guarantee the quality?
A: One year's warranty against B/L date.
If You meet with quality problem, we promise to responsible for it.
Q3: If we don’t find what we want on your website, what should we do?
A: You can email us the descriptions and pictures of the products you need, We will check whether we can make it.
Q4: Can we buy 1 pc of each item for quality testing?
A: Yes, we understand quality test is important and we are glad to send 1pc for quality testing.
