Home > Products > Labsans Testing Systems > LD 21 electronic universal testing machine/Tensile testing machine price
LD 21 electronic universal testing machine/Tensile testing machine price
- 1000 Set / Sets per Month
- guangzhou port
- T/T Credit Card PayPal
Product Details
Place of Origin: | Guangdong, China | Brand Name: | LABSANS | Model Number: | LD21 |
Power: | Electronic | Usage: | Universal Testing Machine |
Product Description
LD21 electronic universal testing machine
Load frame configuration: single column, table, electronic mechanical type
Rated load: 1N, 5N, 25N, 50N, 100N, 250N, 10N, 500N, 1kN, 5kN, 2kN
Test space: single space
Typical samples: plastic, fine wire, fiber and thin wire, biological material, film, adhesive, foam material, packaging, paper products
Technical parameters
Specification Model | LD21 | |
Maximum rated load | kN lbf | 100 22500 |
Load option | N,kN | 1kN,2.5kN,5kN,10kN,20kN,30kN,50kN,100kN |
| lbf | 220,500,1100,2200,4400,6600,11000,22500 |
Frame type | Guide column landing type / table | 2 Guide column landing type |
Experimental space | Single/Double | Single/Double |
Maximum test speed | mm/min In/min | 750 29.5 |
Minimum test speed | mm/min In/min | 0.005 0.0002 |
Displacement resolution | mm in | 0.000047 0.0000019 |
Maximum displacement resolution maximum length | mm in | 1000 39.37 |
Power | V AC | 200-230V AC, 22Amps, 50/60Hz, 4400W |
| Phase number | 1 |
Distance between columns | mm in | 600 23.62 |
Vertical test space beam stroke |
|
|
Standard length | mm in | 1000 39.37 |
Extended length | mm in | 1300 51.2 |
Frame height |
|
|
Standard length | mm in | 2265 89.2 |
Stretch length | mm in | 2565 101 |
Frame width | mm in | 1316 51.8 |
Frame depth | mm in | 957 37.7 |
Frame weight |
|
|
Standard length | kg Lb | 1350 2970 |
Stretch length | kg Lb | 1380 3036 |
LD21 main features of the system
1 full set of compact, high rigid single column and double column load frame configuration;
2: high speed, low vibration MTS motor drive device;
3: maintenance free world class AC servo motor and servo motor;
4: precision pre load ball screw;
5: non clutch driving device, capable of running at full speed under the maximum force;
6: high resolution, digital closed-loop controller (integrated in the load frame);
7: easy test setup and handheld;
8: multi function, easy to operate the Test Work software, with rich and increasing test method standard library (ISO, ASTM, DIN, EN, BS, etc.);
MTS automatic identification of the 9:TEDS load sensor;
10: a full set of optional accessories, fixture, environmental system and extensometer;
11: optional double space (model 44 and 45) to reduce setup time;
12: anti rotating fixture / accessory device;
13: optional T type table;
14: linear guide device to ensure that the movement of high linearity;
15: beam displacement limit protection, overload protection, overheat protection, voltage overload protection, etc.;
16: EU standard integrated security guard;
17: fully comply with the mechanical device 2006/42/EC, low voltage 2006/95/EC, EMC directive 20044/108/EC and GOST-R;
18: durable test space protection;
Shandong Banner International Trade Co., LTD., is your most reliable test helper in material testing industry. Bannerglobal is our brand. The founder and main leaders of our company worked in MTS Systems Corporation more than ten years and provided solutions for various demanding and extremely complex material testing in many fields of China. Our goal is to create the best test experience for customers by providing the best quality products, professional technical support and world-class service to ensure accuracy, repeatability and reliability of test data.
Our product catalog:
Electronic universal testing machine
Hydraulic universal testing machine
Electronic torsion test machine
Tensile testing machine
Pressure testing machine
Pendulum impact testing machine
