High Quality LD25 Floor-standing Electronic Universal Tensile Testing Machine

High Quality LD25 Floor-standing Electronic Universal Tensile Testing Machine thumbnail-1
High Quality LD25 Floor-standing Electronic Universal Tensile Testing Machine thumbnail-2
High Quality LD25 Floor-standing Electronic Universal Tensile Testing Machine thumbnail-3
High Quality LD25 Floor-standing Electronic Universal Tensile Testing Machine photo-1
High Quality LD25 Floor-standing Electronic Universal Tensile Testing Machine photo-2
High Quality LD25 Floor-standing Electronic Universal Tensile Testing Machine photo-3
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shanghai, China
Brand Name:
LABSANS
Model Number:
LD 25
Contact Supplier Request Quote Chat Now
Shandong Banner International Trade Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shanghai, China
Brand Name LABSANS
Model Number LD 25
Power Electronic
Usage Universal Testing Machine









                                    Floor-standing Electronic Universal Testing Tester Machine



LOAD FRAME CONFIGURATION: 2-column, Floor-standing, Electromechanical
RATED FORCE CAPABILITIES:   1 kN, 2.5 kN, 5 kN, 10 kN, 20 kN, 30 kN,  50 kN
TEST SPACE:  single, multistation (optional)
ENVIRONMENTAL SIMULATION:  full range of fuid baths, high-temperature  furnace, environmental chamber
TYPICAL SPECIMENS:  metals, building components, large fasteners,  composites, wood products
Complete selection of compact, high stiffness 1- and 2-column load  frame confgurations

High-speed, low vibration MTS electromechanical drives

  • World-class, maintenance-free AC servomotor and amp
  • Precision, pre-loaded ballscrews
  • Non-clutched drives, rated for full speed at maximum force
High-resolution, digital closed loop controls (integrated into load frame)
Convenient test setup and control handset
Versatile, easy-to-use MTS TestSuite TW software with standards-compliant template library (ASTM, ISO, DIN, EN, BS, and more)
MTS load cells with TEDS self-identifcation capabilities
Complete selection of grips, fxtures, environmental systems  and extensometers
Optional Dual Zone test space (Models 44, 45.504, and 45.105) for maximizing effciency
Anti-rotation grip/fxture mounting
Optional T-Slot table
Linear motion guides for superior alignment
Automatic limit checking of crosshead position, overload, over temperature, over voltage, etc.
Optional EU-compliant Integrated Safety Enclosures
Fully compliant with MACHINERY 2006/42/EC, LOW VOLTAGE 2006/95/EC, EMC Directive 2004/108/EC, and GOST-R
Durable test space protection
Product Description

 High Quality LD25 Floor-standing Electronic Universal Tensile Testing Machine

Specification Model

LD 25 Wide

Maximum rated load

kN

lbf

50

11000

Load option

N,kN

1kN,2.5kN,5kN,10kN,20kN,30kN,50kN



lbf

220,500,1100,2200,4400,6600,11000

Frame type

Guide   column landing type / table

2

Floor-standing

Experimental space

Single/Double

Single

Maximum test speed

mm/min

In/min

750

29.5

Minimum test speed

mm/min

In/min

0.005

0.0002

Displacement resolution

mm

in

0.000047

0.0000019

Maximum displacement   resolution maximum length

mm

in

1000

39.37

Power

V AC

200-230V AC,

22Amps,

50/60Hz,

4400W



Phase number

1

Distance between columns

mm

in

1000

39.37

Vertical Test Space Standard length

mm

in

1000

39.37

Frame height

mm

in

2269

89.3

Frame width

mm

in

1710

67.32

Frame depth

mm

in

957

37.7

Frame Weight Standard length

kg

Lb

1700

3748



Calibration criterion

ISO 7500 0.5/ ASTM E4

ISO 7500 1

Force range

1-100%specified load

0.5%-1%specified load

Maximum test speed under   rated load

100%

Maximum test speed under   rated load

100%

Speed accuracy

Set speed<0.01mm/min:




The speed accuracy is within the range: ±1.0%.

Set speed≥0.01mm/min:

The speed accuracy is within   the range : ±0.2%.

Displacement accuracy

±0.5%

Strain accuracy

ASTM E83 or ISO 8513

security guard

Force overload protection,   displacement limit, voltage overload protection and other

Force overload protection

10%

Data acquisition frequency

1000Hz

Control loop frequency

1000Hz

Motor and drive system

AC servo motor

Ball screw

preload

Displacement measurement   system

Photoelectric encoder

Additional DC regulation   channel

2 channels (example:   resistance extensometer and force sensor)

Additional digital control   channel

1 channels (example: large   deformation and quadrature encoder)





High Quality LD25 Floor-standing Electronic Universal Tensile Testing MachineHigh Quality LD25 Floor-standing Electronic Universal Tensile Testing Machine

Company Information

Shandong Banner International Trade Co., LTD.,  is your most reliable test helper in material testing industry. Bannerglobal is our brand. The founder and main leaders of our company worked in MTS Systems Corporation more than ten years and provided solutions for various demanding and extremely complex material testing in many fields of China. Our goal is to create the best test experience for customers by providing the best quality products, professional technical support and world-class service to ensure accuracy, repeatability and reliability of test data.

High Quality LD25 Floor-standing Electronic Universal Tensile Testing MachineHigh Quality LD25 Floor-standing Electronic Universal Tensile Testing Machine

Our Services

1. Pre-service

    24 Hours online service for your consult.

    Help choose right model,and a series  of service,person,advise.

2. Middle service

    --Give you best offer

    --Provide discount for many sets order

    --Do customer's request:

    --Choose payment term you convienent.

    --Promptly production and delivery,inform you in time.

    --Can provide invoice value as you like to decrease your tax.

3. After sale service

   --1 year warranty service and all life maintenance.

   --Technical Egineer are avalible for oversea trainning.

   --Free change for some parts

   --Remote control technical consult

   --Free installation DVD

   --Maintenance plan

4. Commitment:

We will sign a letter of commitment while we sign the contract, which will improve your confidence to us.

If you face any problems in future during testing process we promise we will give you a reply within 48 hours and solution provide within 3 working days. After service phone :400-168-8048





Packaging

Packed by standard export fumigated wooden cases.

Ship from Qingdao port, is expected to arrive about 30days
