Microcomputerized Electronic Pressure/Compression Testing Machine 100KN
- 1000 Set / Sets per Month
- Qingdao Port
- T/T D/P D/A Credit Card PayPal
Product Details
Place of Origin: | Shanghai, China | Brand Name: | LABSANS | Model Number: | LD41.105-D |
Power: | Electronic | Usage: | Compression Testing Machine |
Product Description
Computer Controlled Electronic Pressure Testing Machine
Equipment overview:
LD41.105microcomputer controlled electronic pressure testing machine is a new type of material testing machine with electronic technology and mechanical transmission. It has a wide range of loading speed and range. It can also be controlled by the load and displacement.
Main function:
It is specially used to test the compressive strength of cement mortar materials and meet the national standard GB/T17671-1999 "cement mortar strength test method", but also meet the test requirements of ASTM, ISO and other standards.
Main features:
1: the use of high-speed DSP platform, its high integration, powerful control, data processing ability, high reliability, is the use of other processors can not match the test machine.
2: can carry out the test force, deformation, displacement and other rate control and maintain.
USB1.1 3: communication, communication rate is 12Mb/s, the use of full speed mode, bulk transfer mode.
4: system board uses 4 layers of PCB unique anti interference routing method, strong anti-interference ability.
5: in addition to the power interface, the other interfaces are the standard USB type interface, plug and play interface such interface can be used to achieve hot swap, that is, plug and play function. Interface features can be set up by software online. The interface neat layout reasonable, convenient plug.
6: the whole control system has a very high cost, high reliability.
7: the whole test process is controlled by microcomputer, and the load value, displacement, deformation, test speed and test curve are displayed in real time.
8: uses microcomputer for data processing and analysis. The test results can be saved automatically. After the end of the experiment, the test curve can be re - up.
9: full Chinese Windows platform under the test software, with a strong data and graphics processing functions, can print out the complete test report and test curve.
10: have the perfect protection, overload protection, emergency stop and other safety protection function.
Meet standards:
GB/T17671-1999 "cement mortar strength test method"
Application industry:
Measurement and quality control; high school; Research Institute; commodity inspection and arbitration, technical supervision departments; building materials ceramics; other industries.
Original configuration:
Compression jig 1 set
Scalable configuration:
Protective cover
Technical parameters:
Model | LD41.105-D | |
Measurement parameters | Maximum test force | 100kN |
Accuracy class | 1 | |
Test force measurement range | Full range 0.2%~100% | |
Test force resolution | Maximum test force 1/300000 | |
Test force measurement accuracy | Value ±1% | |
Control parameter | Distance between plates | 220mm |
Upper pressing plate diameter | Φ110mm | |
Lower pressing plate diameter | Φ130mm | |
Column number | 2 | |
Two column net distance | 300mm | |
Maximum stroke | 100mm | |
Maximum speed | 50mm/min | |
Other | Motor power | 1500W |
Power Supply | 380V/50HZ | |
Weight | 1000kg | |
Host size | 1230×700×1300 |
Packing & Shipping:
Fumigation and by standard export wooden case.
Our Services
1. Pre-service
24 Hours online service for your consult.
Help choose right model,and a series of service,person,advise.
2. Middle service
--Give you best offer
--Provide discount for many sets order
--Do customer's request:
--Choose payment term you convienent.
--Promptly production and delivery,inform you in time.
--Can provide invoice value as you like to decrease your tax.
3. After sale service
--1 year warranty service and all life maintenance.
--Technical Egineer are avalible for oversea trainning.
--Free change for some parts
--Remote control technical consult
--Free installation DVD
--Maintenance plan
4. Commitment:
We will sign a letter of commitment while we sign the contract, which will improve your confidence to us.
5. Good Packaging:
Good Packaging: Simulation Animatronic Customer Triceratops are covered with air bubble film before put them into the wooden case, which not only has good shock absorption, impact resistance, heat sealing and also has the advantages of nontoxic, odorless, moisture corrosion, good transparency etc.
