Help CenterHigh Quality 500N Universal Tensile Testing Equipment
Related Products
-
100kn Universal Tensile Testing Machine/ Tensile TesterUS$ 5,000 - 10,000MOQ: 1 Set -
Chinese Manufacture Universal 100kg Tensile Testing Machine PriceUS$ 5,000 - 10,000MOQ: 1 Set
-
300KN Uiversal Testing MachineNegotiableMOQ: 1 Set
-
500Nm Electric Torsion Testing Machine PriceNegotiableMOQ: 1 Set
-
200Nm Electronic Torsion Tester/ Torsion Testing MachineNegotiableMOQ: 1 Set
electronic universal testing machine
Load frame configuration: single column, table, electronic mechanical type
Rated load: 1N, 5N, 25N, 50N, 100N, 250N, 10N, 500N, 1kN, 5kN, 2kN
Test space: single space
Typical samples: plastic, fine wire, fiber and thin wire, biological material, film, adhesive, foam material, packaging, paper products
main features of the system
1 full set of compact, high rigid single column and double column load frame configuration;
2: high speed, low vibration MTS motor drive device;
3: maintenance free world class AC servo motor and server;
4: precision pre load ball screw;
5: non clutch driving device, capable of running at full speed under the maximum force;
6: high resolution, digital closed-loop controller (integrated in the load frame);
7: easy test setup and handheld;
8: multi function, easy to operate the Test Work software, with rich and increasing test method standard library (ISO, ASTM, DIN, EN, BS, etc.);
MTS automatic identification of the 9:TEDS load sensor;
10: a full set of optional accessories, fixture, environmental system and extensometer;
11: optional double space (model 44 and 45) to reduce setup time;
12: anti rotating fixture / accessory device;
13: optional T type table;
14: linear guide device to ensure that the movement of high linearity;
15: beam displacement limit protection, overload protection, overheat protection, voltage overload protection, etc.;
16: EU standard integrated security guard;
17: fully comply with the mechanical device 2006/42/EC, low voltage 2006/95/EC, EMC directive 20044/108/EC and GOST-R;
18: durable test space protection;
Specification model |
LD21 |
|
Maximum rated load |
kN |
1 |
Load option |
N,kN |
1N,5N,10N,25N,50N,100N, 250N,500N,1kN |
|
|
|
Frame type |
Guide column landing type / table |
1 Table type |
experimental space |
Single/Double |
Single |
Maximum test speed |
mm/min |
3000 |
Minimum test speed |
mm/min |
0.005 |
Displacement resolution |
mm |
0.00005 |
Maximum displacement resolution maximum length |
mm in |
650 25.6 |
Power |
V AC |
200-230V AC, 5Amps, 50/60Hz, 1000W |
|
Phase number |
1 |
Distance between columns |
mm in |
100* 3.94* |
Vertical test space beam stroke |
|
|
Standard length |
mm in |
650 25.6 |
Extended length |
mm in |
950 37.4 |
Frame height |
|
|
Standard length |
mm in |
1296 51 |
Stretch length |
mm in |
1596 62.83 |
Frame width |
mm in |
700 27.56 |
Frame depth |
mm in |
632 24.88 |
Frame weight |
|
|
Standard length |
kg Lb |
129 283.8 |
Stretch length |
kg Lb |
160 352 |
Calibration criterion |
ISO 7500 0.5/ ASTM E4 |
ISO 7500 1 |
|
Force range |
1-100%specified load |
0.5%-1%specified load |
|
Maximum test speed under rated load |
100% |
||
Maximum test speed under rated load |
100% |
||
Speed accuracy |
Set speed<0.01mm/min:
The speed accuracy is within the range: ±1.0%. Set speed≥0.01mm/min: The speed accuracy is within the range : ±0.2%. |
||
Displacement accuracy |
±0.5% |
||
Strain accuracy |
ASTM E83 ISO 8513 |
||
security guard |
Force overload protection, displacement limit, voltage overload protection and other |
||
Force overload protection |
10% |
||
Data acquisition frequency |
1000Hz |
||
Control loop frequency |
1000Hz |
||
Environmental requirements |
|
||
Motor and drive system |
AC servo motor |
||
Ball screw |
preload |
||
Displacement measurement system |
Photoelectric encoder |
||
Additional DC regulation channel |
2 channels (example: resistance extensometer and force sensor) |
||
Additional digital control channel |
1 channels (example: large deformation and quadrature encoder) |
||
Shandong Banner International Trade Co., LTD., is your most reliable test helper in material testing industry. Bannerglobal is our brand. The founder and main leaders of our company worked in MTS Systems Corporation more than ten years and provided solutions for various demanding and extremely complex material testing in many fields of China. Our goal is to create the best test experience for customers by providing the best quality products, professional technical support and world-class service to ensure accuracy, repeatability and reliability of test data.
Our product catalog:
Electronic universal testing machine
Hydraulic universal testing machine
Electronic torsion test machine
Tensile testing machine
Pressure testing machine
Pendulum impact testing machine
Q1: I want to buy your products, how can I pay?
A :You can pay via T/T , T/C, Western Union,MoneyGram or other payment terms we reach agreement.
Q2: How can you guarantee the quality?
A: One year's warranty against B/L date.
If You meet with quality problem, we promise to responsible for it.
Q3: If we don’t find what we want on your website, what should we do?
A: You can email us the descriptions and pictures of the products you need, We will check whether we can make it.
Q4: Can we buy 1 pc of each item for quality testing?
A: Yes, we understand quality test is important and we are glad to send 1pc for quality testing.
Cathy Wang
Shandong banner international trade Co.,Ltd
Web:
www.bannerglobal.en.china.cn
Tel: +86 537 3167400 Fax: +86 537 3165401
Mob: +86 15898600195
