CK61160 Heavy Duty Automatic Lathe
YIMAKE CK61160 CNC heavy duty horizontal lathe machine is universal standard automatic machining equipment for metal processing,capable of semi finish machining and finish machining of machinery components and parts,with the main characters such as reliable structure,easy operating and economica for using.
This series lathe machine mainly used for turning the internal and external cylindrical surface,conical surface and other rotating surfaces,and turning internal and external pipe threads such as metric,inch,module,DP threads etc.
Main Features:
Integral machine bed adopts high strength iron to realize high rigidity and precision;
Ultrasonic frequency quenched guide-ways are hard enough for good wear-resistance;
Carrigge and guide way contact surface pasted with Turcite B to maintain long-term accuracy.
Detailed specification:
SPECIFICATION OF YIMAKE LATHE MACHINE | |||
ITEMS |
UNIT |
CK61160 CNC Lathe |
|
Capacity |
Swing over bed |
mm |
Φ1600 |
Swing over gap |
mm |
- |
|
Swing over cross slide |
mm |
Φ1200 |
|
Distance between centers |
mm |
1500/3000 |
|
Width of bed way |
mm |
755 |
|
Max. load capacity |
T |
5 |
|
Spindle |
Spindle bore |
mm |
Φ130 |
Spindle bore taper |
- |
MetricΦ140, MT#6 |
|
Spindle nose type |
- |
C15 |
|
Spindle speed steps |
- |
Manual 2 steps |
|
Spindle speed range |
rpm |
4-300 |
|
Chuck size |
mm |
Φ1000 |
|
Chuck type |
- |
4-jaw manual |
|
Turret |
Turret type |
- |
NC turret 4 position |
Tool shank size |
mm |
40x40 |
|
Carriage |
X axis travel |
mm |
720 |
Z axis travel |
mm |
1350/2850 |
|
X axis rapid traverse speed |
mm/min |
4000 |
|
Z axis rapid traverse speed |
mm/min |
4000 |
|
Tailstock |
Tailstock quill diameter |
mm |
Φ140 |
Tailstock quill taper |
- |
MT#6 |
|
Tailstock quill travel |
mm |
300 |
|
Motors |
Main spindle motor |
kW |
22 |
Coolant pump motor |
kW |
0.125 |
|
Accuracy |
Positioning accuracy |
mm |
0.020 |
Repositioning accuracy |
mm |
0.010 |
|
Dimensions |
Width x Height |
mm |
2300x2400 |
Length |
mm |
5000/6500 |
|
Weight |
Net weight |
T |
15.0/16.5 |
Standard Accessories:
Fanuc CNCsystem,NC turret 4 position,Coolant system,Lubrication system,Lighting system,Mobile
hand-wheel,Semi-shield,Manual tailstock,Chuck,Rear support bracket, Pad iron etc.
Optional Accessories:
CNC system(Simens,Fagor,GSK,KND),Turret(Servo,hydraulic,power),Chip conveyor,Air conditioner,Full-shield,Hydraulic tailstock,Chuck,Center rest,Follower rest,Signal light,Grinding attachment etc.
Customizing support:
Painting color,headstock height,lathe bed length etc.
Standard package:
Plywood packing box with steel pallet and iron framework.
