CK6180 CNC Lathe Machine
YIMAKE CK6180 CNC horizontal lathe machine tool is universal standard automatic machining equipment for metal processing,capable of semi finish machining and finish machining of machinery components and parts,with the main characters such as reliable structure,easy operating and economical for using.
This series lathe machine mainly used for turning internal and external cylindrical surface,conical surface and other rotating surfaces,and turning internal and external pipe threads such as metric,inch,module,DP threads etc.
Main Features:
Integral machine bed adopts high strength iron to realize high rigity and precision;
Ultrasonic frequency quenched guide-way are hard enough for good wear-resistance;
Carriage and guide way contact surface pasted with Turcite B to maintain long-term accuracy.
Detailed Specifications:
SPECIFICATION OF YIMAKE LATHE MACHINE | |||
ITEMS |
UNIT |
CK6180 CNC Lathe |
|
Capacity |
Swing over bed |
mm |
Φ800 |
Swing over gap |
mm |
Φ1000 |
|
Swing over cross slide |
mm |
Φ550 |
|
Distance between centers |
mm |
1500/2000/3000 |
|
Width of bed way |
mm |
550 |
|
Max. load capacity |
T |
3 |
|
Spindle |
Spindle bore |
mm |
Φ104 |
Spindle bore taper |
- |
MetricΦ120, MT#5 |
|
Spindle nose type |
- |
C11 |
|
Spindle speed steps |
- |
Step-less |
|
Spindle speed range |
rpm |
0-1000 |
|
Chuck size |
mm |
Φ315 |
|
Chuck type |
- |
3-jaw manual |
|
Turret |
Turret type |
- |
NC turret 4 position |
Tool shank size |
mm |
32x32 |
|
Carriage |
X axis travel |
mm |
420 |
Z axis travel |
mm |
1350/1850/2850 |
|
X axis rapid traverse speed |
mm/min |
4000 |
|
Z axis rapid traverse speed |
mm/min |
4000 |
|
Tailstock |
Tailstock quill diameter |
mm |
Φ104 |
Tailstock quill taper |
- |
MT#5 |
|
Tailstock quill travel |
mm |
250 |
|
Motors |
Main spindle motor |
kW |
Servo 15 |
Coolant pump motor |
kW |
0.125 |
|
Accuracy |
Positioning accuracy |
mm |
0.020 |
Repositioning accuracy |
mm |
0.010 |
|
Dimensions |
Width x Height |
mm |
1690x1740 |
Length |
mm |
3890/4390/5390 |
|
Weight |
Net weight |
T |
4.6/5.0/5.4 |
Standard Accessories:
Fanuc CNC system,NC turret 4 position,Coolant system,Lubrication system,Lighting system,
Mobile hand-wheel,Semi-shield,Manual tailstock,Chuck,Rear support bracket, Pad iron etc.
Optional Accessories:
CNC system(Simens,Fagor,GSK,KND),Turret(Servo,hydraulic,power),Chip conveyor,Air conditioner,Full-shield,Hydraulic tailstock,Chuck,Center rest,Follower rest,Signal light,Grinding attachment etc.
Customizing support:
Painting color,headstock height,lathe bed length etc.
Standard package:
Plywood packing box with steel pallet and iron framework.
